Flexem FR-T0400K Temperature Module - 4-Channel Universal Input

Meet the FR-T0400K temperature module - your smart solution for precise thermal monitoring. This versatile module reads multiple sensor types with excellent accuracy.

Main Benefits

• 4 input channels - Monitor multiple points
• Universal compatibility - Works with 9 thermocouple types
• High accuracy - ±0.3% for reliable data
• Compact design - Saves control panel space
• Easy setup - Simple configuration

Technical Specifications

• Product Model: FR-T0400K Temperature Module
• Input Channels: 4 isolated channels
• Supported Sensors: K, J, R, S, B, E, T, N, C thermocouples
• RTD Support: PT100, PT1000, Cu50, Cu100, NI100, NI1000
• Temperature Range: -200°C to +850°C (depends on sensor)
• Measurement Accuracy: ±0.3% or ±1°C (thermocouples)
• NTC Accuracy: ±0.1% or ±1°C
• Conversion Time: 100ms per channel typical
• Input Impedance: >1MΩ for voltage inputs
• Power Supply: 5V DC ±5%
• Current Consumption: 50mA maximum
• Isolation Voltage: 500V AC between channels
• Operating Temperature: -10°C to +60°C
• Storage Temperature: -20°C to +70°C
• Humidity Range: 10% to 95% non-condensing
• Connection Type: Removable terminal block
• Module Dimensions: 111mm × 18mm × 76mm
• Product Weight: 65 grams

Quick Installation

Mount on DIN rail. Connect 5V DC power. Wire temperature sensors. Set sensor type in software. Calibrate if needed. Start monitoring.

Ideal Applications

• Industrial oven control
• Plastic processing machines
• Food temperature monitoring
• HVAC system control
• Laboratory equipment

Worldwide Shipping

Fast delivery via FedEx, UPS, DHL. Orders ship within 24 hours. Tracking information provided.

Package Contents

• Flexem FR-T0400K Temperature Module
• Installation guide
• Technical specifications

Warranty Protection

12-month quality guarantee from delivery date. Reliable performance assured.

Expert Questions & Answers

What thermocouple types are supported?

This module supports 9 common types: K, J, R, S, B, E, T, N, and C thermocouples for various temperature ranges.

How do I choose between thermocouple and RTD?

Use thermocouples for higher temperatures and RTDs for better accuracy in lower temperature applications.

Can I mix different sensor types on one module?

Yes, each channel can be independently configured for different sensor types through software settings.

What cable type should I use for sensors?

Use proper thermocouple extension wires or shielded cables for RTDs to maintain measurement accuracy.

How often should I calibrate the module?

Under normal conditions, annual calibration is recommended for critical applications to maintain accuracy.
