1756-OB32 | Allen-Bradley ControlLogix High-Density Output Module
Manufacturer:
Allen-Bradley
Product No.:
1756-OB32A
Condition:
In Stock
Product Type:
High-Density DC Output
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Etibarlı Qlobal Avtomatlaşdırma Hissələri Təchizatçısı
Səhmimizdə olan geniş çeşiddə sənaye avtomatlaşdırma ehtiyat hissələri təklif edirik. Bütün məhsullar 12 aylıq zəmanətlə və keyfiyyət problemləri üçün 30 günlük geri ödəniş ilə gəlir.
Allen-Bradley 1756-OB32 ControlLogix DC Output Module
The 1756-OB32 provides high-density output control in compact spaces. This 1756-OB32 module offers 32 DC output points for efficient industrial automation.
Key Benefits
- 32 Output Points in single slot design
- Fast response: 60µs off to on delay
- Wide voltage range: 10-31.2V DC operation
- Individual LED indicators for each channel
- Space-saving high-density configuration
Technical Specifications
- Brand: Allen-Bradley
- Series: ControlLogix
- Part Number: 1756-OB32
- Module Type: High-Density DC Output
- Output Points: 32 points (2 groups of 16)
- Voltage Range: 10-31.2V DC
- Response Time: 60µs nominal off-on, 200µs on-off
- Current per Point: 0.5A @ 50°C, 0.35A @ 60°C
- Module Current: 16A @ 50°C, 10A @ 60°C
- Power Dissipation: 4.8W maximum
- Backplane Power: 300mA @ 5V, 2mA @ 24V
- Isolation Voltage: 250V continuous
- Surge Current: 1A for 10ms per point
- Leakage Current: 0.5mA per point maximum
- Operating Temperature: 0°C to 60°C
- Terminal Blocks: 1756-TBCH, 1756-TBS6H
Installation Features
- Single slot installation
- Works in local or remote chassis
- Removable terminal blocks for easy maintenance
- 32 LED status indicators
- Compatible with all ControlLogix processors
Application Uses
- Control pilot lights and indicators
- Operate relays and contactors
- Drive solenoids and buzzers
- Panel annunciator systems
- Space-constrained installations
Warranty & Shipping
Includes 12-month warranty coverage. Fast international shipping via FedEx, UPS, DHL.
Frequently Asked Questions
- How many output groups does it have? Two groups of 16 points each.
- What is the maximum operating temperature? 60 degrees Celsius.
- Are status indicators included? Yes, 32 individual LED indicators.
- What terminal blocks are compatible? 1756-TBCH and 1756-TBS6H.
- Is external fusing recommended? Yes, 800mA fuse for protection.
For complete technical information: Download full specification sheet here.
