Emerson EZ1080 8mm Eddy Current Sensor for Precision Shaft Measurement

Product Overview

• The EZ1080 series from Emerson delivers reliable performance.
• This 8mm eddy current sensor measures shaft displacement and position.
• It suits critical applications in turbines, compressors, and gearboxes.
• The sensor offers a robust design for harsh industrial environments.
• You can use it for dynamic monitoring of radial and axial movement.

Key Technical Specifications

• Brand: Emerson
• Model: EZ1080-23-18-010
• Linear Measurement Range: 2 mm (80 mils)
• Initial Air Gap: 0.5 mm (20 mils)
• Incremental Scale Factor (ISF): 7.87 V/mm or 8 V/mm ±5%
• Deviation from Straight Line (DSL): ±0.025 mm (±1 mil)
• Minimum Recommended Target Size: 20mm (0.79")
• Minimum Recommended Shaft Diameter: 25mm (0.98")
• Target Material: Ferromagnetic steels like AISI 4140 or 1035.
• Protection Class: IP67 (IP68 with optional test certificate)
• Operating Temperature: -35°C to +180°C (Sensor with 1m cable)

Environmental Durability and Construction

• The sensor case uses durable stainless steel for long service life.
• Its tip features glass-fiber reinforced PEEK for excellent wear resistance.
• The integrated FEP cable and connector withstand temperatures up to 150°C.
• It maintains a strong seal against differential pressure up to 10000 hpa.
• This construction ensures reliable operation in demanding conditions.

Global Compliance and Hazardous Area Approvals

• The sensor meets CE, ATEX, IEC-Ex, and CSA international standards.
• It also carries CCC (China), CCOE (India), and KTL (Korea) certifications.
• You can use it in Intrinsically Safe (ia) and Increased Safety (ec) areas.
• Its temperature classification supports T2, T4, and T6 requirements.
• This makes the EZ1080 suitable for global projects.

Installation Guidelines

• Always establish the correct initial air gap of 0.5 mm during setup.
• Ensure the target shaft meets the minimum diameter recommendation.
• Use the M10x1 thread for secure mounting in your application.
• The 180mm unthreaded length provides flexibility for placement.
• Verify the target material is compatible for accurate measurements.

Packaging and Shipping

• The package includes one EZ1080-23-18-010 sensor with a 1-meter cable.
• We ship all orders promptly via major carriers like FedEx, UPS, and DHL.
• You will receive tracking information immediately after your order ships.

Frequently Asked Questions (FAQ)

• What is the typical application for this sensor? It measures dynamic displacement and speed on turbomachinery.
• Can I use this sensor in an explosive atmosphere? Yes, it carries multiple hazardous area approvals for safe use.
• What is the difference between API and ISO scale factors? They are different calibration standards; please specify your need.
• How do I ensure measurement accuracy? Follow the target size and material guidelines provided in the specs.
