GE Fanuc IC693CHS392 10-Slot Expansion Baseplate
Product Overview
The GE Fanuc IC693CHS392 is a 10-slot expansion baseplate for Series 90-30 PLC systems. It adds more space for I/O modules. Connects to your main CPU baseplate. Perfect for larger control systems.
Key Benefits
10 I/O slots. Panel mounting. 25-pin expansion port. For indoor use. Easy to install. Works with Series 90-30.
Technical Specifications
Brand: GE Fanuc
Series: Series 90-30
Model: IC693CHS392
Product Type: Expansion Baseplate
I/O Slots: 10
Power Supply Slot: 1
Expansion Port: 25-pin D-shell female
Voltage: 5 VDC
Current: 150 mA
Max Cable Length: 50 feet (15 meters)
Dimensions: 443 x 142 x 130 mm (17.44 x 5.59 x 5.12 in)
Mounting: Panel Mount
Compatible CPUs: 331, 340, 341, 350 and higher
Max Baseplates: Up to 7 (depends on CPU)
Environment: Indoor Use Only
Package Contents
One (1) GE Fanuc IC693CHS392 expansion baseplate. Mounting hardware.
Easy Installation
Mount on panel using provided tabs. Connect to CPU baseplate with expansion cable. Keep cable under 50 feet. Ground properly.
Compatibility Notes
This IC693CHS392 baseplate works with standard Series 90-30 I/O modules. Not for intelligent modules (PCM, ADC, CMM, BEM330).
Frequently Asked Questions
How many modules can it hold?
It provides 10 slots for standard Series 90-30 I/O and option modules.
What is the maximum cable length?
The expansion cable must not exceed 50 feet (15 meters) for reliable operation.
Which CPUs is it compatible with?
It works with CPUs 331, 340, 341, 350 and higher models.
Can I install intelligent modules?
No, intelligent modules like PCM, ADC, and CMM must be installed on the CPU baseplate.
How is it powered?
It requires a separate power supply module installed in its power supply slot.
