Woodward 8440-2052 easYgen-3200 Advanced Genset Controller

The Woodward 8440-2052 delivers sophisticated control for complex power generation systems managing up to 32 generator units. This advanced controller features comprehensive load sharing capabilities and auto mains failure functionality. The 8440-2052 operates as an easYgen-3200-P2 model with three freely configurable PID controllers. Its robust design supports extensive I/O configurations for complete engine-generator monitoring and protection.

Technical Specifications & Performance Data

• Brand: Woodward
• Model Number: 8440-2052 Control Unit
• Product Series: easYgen-3200-P2 Controller
• Front Panel Dimensions: 282mm W x 216mm H x 96mm D
• Back Panel Dimensions: 250mm W x 227mm H x 50mm D
• Power Supply Range: 8 to 40 VDC (12/24 VDC Standard)
• Maximum Power Consumption: 17 Watts
• Measuring Frequency Range: 40-85 Hz (50/60 Hz Standard)
• Contact Material: AgCdO for reliable switching

Input/Output Configuration & Capabilities

• Three freely configurable analog inputs with scaling capability
• Up to twelve configurable discrete inputs and outputs
• Thirty-two external discrete I/Os via CANopen network
• Sixteen external analog inputs through CANopen interface
• Four external analog outputs via CANopen connectivity
• Five amp CT inputs for current transformer connections
• Magnetic/switching pickup for precise speed measurement
• Twelve discrete alarm outputs with ten configurable channels

Control Functions & Operational Modes

• Advanced load sharing across multiple generator sets
• Comprehensive breaker control logic for safe operation
• Auto mains failure (AMF) for automatic backup power
• Stand-by operation mode for emergency power systems
• Single or multiple unit operations for flexible deployment
• Three independent PID controllers for precise regulation
• Speed, frequency, and voltage setpoint configuration
• Power factor and excitation control for optimal performance

Measurement & Protection Features

• Multiple alternator winding measurement compatibility
• Supports 3p-3w, 3p-4w, 1p-2w, and 1p-3w configurations
• Comprehensive generator protection with adjustable setpoints
• Engine monitoring with configurable alarm thresholds
• Mains protection with voltage and frequency monitoring
• Real-time parameter tracking and data logging
• Built-in operator interface for local control and monitoring

Installation & Mounting Information

• Front panel mounting design for easy installation
• Plastic housing with integrated operator interface
• Standard 12/24 VDC power supply compatibility
• Wide voltage input range from 8 to 40 VDC
• Compact dimensions for space-constrained installations
• CANopen network support for distributed systems
• Easy integration with existing power management systems

Packaging & Shipping Details

• Each package contains one Woodward 8440-2052 controller
• Includes complete installation manual and mounting kit
• Worldwide shipping via FedEx, UPS, and DHL carriers
• Full tracking and insurance coverage for all shipments
• Quick dispatch within 2-3 business days for stock items

Professional FAQ

• What is the maximum number of gensets this controller can manage?
• The 8440-2052 can control up to 32 generator units in single or multiple operation modes.
• What type of PID controllers does this model include?
• It features three freely configurable PID controllers for precise process control applications.
• What power supply voltage range does this unit accept?
• The controller operates on 8 to 40 VDC, making it compatible with standard 12/24V systems.
• How many configurable discrete I/Os does this controller provide?
• It offers up to 12 configurable discrete I/Os plus 32 additional via CANopen network.
• What alternator winding types can this unit measure?
• It supports 3p-3w, 3p-4w, 1p-2w, and 1p-3w winding configurations for various alternators.
