Bently Nevada 3300 XL 8mm Global Certified Proximity Probe

Meet international safety standards with the Bently Nevada 3300 XL 8 mm Proximity Probe, featuring triple certifications and extended reach design.

Global Compliance Solution

• Manufacturer: Bently Nevada
• Product Series: 3300 XL 8 mm Proximity Probes
• Complete Model: 330104-14-19-10-11-05
• Global Certifications: CSA, ATEX, and IECEx Approved
• Safety Feature: FluidLoc cable for hazardous areas
• Origin: Manufactured in U.S.A.

Advanced Configuration Details

• 330104 - 8mm Probe with M10x1 thread and armored protection
• 14 - Unthreaded length: 140mm extended section
• 19 - Case length: 190mm overall dimensions
• 10 - Cable length: 1.0 meter (3.3 feet)
• 11 - Connection: Miniature coaxial ClickLoc with protector and FluidLoc cable
• 05 - Certifications: CSA, ATEX, and IECEx safety approvals

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe System
• Probe Design: 8mm diameter with M10 x 1 metric threading
• Total Case Length: 190mm stainless steel construction
• Unthreaded Section: 140mm extended length
• Cable Technology: FluidLoc cable for hazardous environments
• Cable Length: 1.0 meter (3.3 feet)
• Connector System: Miniature coaxial ClickLoc with protector
• Electrical Resistance: 7.59 Ω ± 0.50 Ω (1.0m cable)
• Tip Material: Polyphenylene sulfide (PPS)
• Housing Material: AISI 303/304 stainless steel
• Sealing Technology: Viton® O-ring for pressure containment

Electrical Performance

• Power Supply: -17.5 Vdc to -26 Vdc operating range
• Output Impedance: 50 Ω
• Voltage Sensitivity: Less than 2 mV per volt input variation
• Maximum Current Draw: 12 mA consumption
• Optimal Sensing Gap: 1.27 mm to AISI 4140 steel target

Environmental & Safety Ratings

• Operating Temperature: +18°C to +27°C (+64°F to +80°F)
• Maximum Altitude: 2000 meters operational rating
• CSA Certification: Complies with Canadian standards
• ATEX Approval: Meets European hazardous area requirements
• IECEx Certification: International safety standard compliance

Packaging & Global Delivery

• Includes 190mm extended length proximity probe
• 140mm unthreaded section for flexible installation
• FluidLoc cable with ClickLoc connector and protector
• 1.0 meter specialized hazardous area cable
• International shipping via FedEx, UPS, and DHL
