Bently Nevada 3300 XL 8mm ATEX Certified Vibration Probe
The Bently Nevada 3300 XL 8 mm probe delivers exceptional machinery protection with global certifications. This industrial sensor features explosion-proof approvals for hazardous environments. Its robust design ensures reliable performance in critical applications. We explore its complete technical profile below.
Core Product Identity
- Brand: Bently Nevada
- Series: 3300 XL Vibration Monitoring
- Model: 330140-08-30-01-05
- Probe Diameter: 8mm Industrial Grade
- Certifications: CSA, ATEX, IECEx Approved
- Origin: Manufactured in United States
Configuration Breakdown
- Case Dimension: 0.8 inch rugged stainless steel housing
- Cable Length: 3.0 meters extended reach capability
- Connection System: ClickLoc coaxial with standard cable
- Safety Certification: Complete hazardous area approvals
- Application Ready: Factory configured for immediate use
Performance Specifications
- Electrical Resistance: 8.17 Ω ± 0.50 for 3.0m version
- Measurement Sensitivity: 7.87 V/mm (200 mV/mil) standard output
- System Accuracy: Maintains ±5% in standard 5-meter configurations
- Temperature Range: Operates from -52°C to +177°C wide span
- Linear Performance: Better than ±0.025 mm deviation from straight line
Engineering Excellence
- TipLoc patented molding ensures permanent tip-to-body bond
- CableLoc technology delivers 330 N connection strength
- 8mm robust construction provides superior physical protection
- PPS plastic tip material offers excellent chemical resistance
- Viton O-ring maintains seal under differential pressure conditions
Environmental Compliance
- Humidity Performance: Less than 3% ASF change at 93% RH
- International Standards: Complies with IEC 68-2-3 testing protocols
- Explosion Proof: ATEX, IECEx and CSA certifications included
- Thermal Stability: Reliable operation across extreme temperatures
- Sealing Integrity: Maintains performance in pressurized environments
Shipping & Delivery Information
- Package Contents: One complete 330140-08-30-01-05 probe unit
- Protective Packaging: Industrial-grade materials ensure safe transit
- Global Logistics: FedEx, UPS, DHL express shipping available
- Order Tracking: Real-time shipment monitoring provided
- Quick Dispatch: Most orders ship within 24 business hours
Installation Advantages
- ClickLoc connector enables quick, secure mating operations
- Standard cable provides flexibility for various routing requirements
- Stainless steel case withstands harsh industrial environments
- 3.0 meter length offers installation flexibility in tight spaces
- Explosion-proof design suits hazardous location applications
Frequently Asked Questions
What certifications does this probe model include?
This model carries CSA, ATEX, and IECEx certifications for global use in hazardous areas.
How does the 3.0 meter length benefit installation?
The extended cable length provides greater flexibility for machine layout and sensor placement.
What is the electrical specification for this probe?
The 3.0 meter version has 8.17 Ω nominal resistance with ±0.50 Ω tolerance range.
Can this probe handle explosive environments?
Yes, the ATEX and IECEx approvals make it suitable for explosive atmosphere applications.
What makes the 8mm design more durable?
The larger diameter provides thicker insulation and stronger physical construction.
