Buy IC697ALG444 90-70 PLC Module | GE Fanuc
Manufacturer:
GE
Product No.:
IC697ALG444
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Vertrauenswürdiger globaler Lieferant für Automatisierungsteile
Wir bieten eine große Auswahl an vorrätigen Ersatzteilen für die industrielle Automatisierung. Alle Produkte haben eine 12-monatige Garantie und eine 30-tägige Rückerstattung bei Qualitätsproblemen.
GE Fanuc IC697ALG444: 16-Channel Analog Input Module
The GE Fanuc IC697ALG444 delivers precise analog signal acquisition for industrial automation systems. This high-density 16-channel module offers exceptional accuracy and reliability for Series 90-70 PLC applications.
Technical Specifications
- Brand: GE Fanuc
- Model: IC697ALG444 (Complete Suffix)
- Series: Series 90-70 PLC
- Channels: 16 analog inputs
- Voltage Range: ±10V DC
- Current Range: 4-20mA
- Accuracy: ±2mV at 10V calibration
- Resolution: 16-bit high precision
- Input Impedance: 1MΩ voltage, 250Ω current
- Sampling Rate: 100ms per channel typical
- Power Supply: 5V DC from backplane
- Operating Temperature: 0°C to 60°C
- Isolation: 1500V channel-to-backplane
- Connector: Gold-plated headers
- Compatible Terminal: IC697ACC775 required
Compatibility & Integration
- Series 90-70 PLC systems
- VME-bus standard backplanes
- Genius I/O networks
- Field Control I/O systems
- Redundant configurations supported
- Multiple CPU platforms
Signal Characteristics
- Voltage Input: -10V to +10V DC
- Current Input: 4-20mA loop powered
- Common Mode Rejection: >120dB @ 60Hz
- Noise Immunity: 1000V/microsecond slew rate
- Update Rate: 10 channels/second typical
- Calibration: Factory pre-calibrated
Environmental Ratings
- Operating Temp: 0°C to 60°C (32°F to 140°F)
- Storage Temp: -40°C to 85°C (-40°F to 185°F)
- Humidity: 5-95% non-condensing
- Vibration: 2G @ 10-500Hz
- Shock: 30G operational
- Altitude: Up to 2000 meters
Package & Support
- Single unit packaging
- Global shipping: FedEx, UPS, DHL
- Delivery: 3-5 business days
- Warranty: 12 months
- RoHS compliant: Yes
- Origin: GE Fanuc factory
Frequently Asked Questions
- What terminal block is required? IC697ACC775 terminal block must be used.
- Can voltage and current inputs be mixed? Yes, each channel can be configured independently.
- What is the calibration accuracy? ±2mV at 10V reference voltage.
- Is external power required? No, powered from PLC backplane 5V DC.
- What PLC systems are compatible? Series 90-70 with VME-bus architecture.
