Schneider Electric 140XTS00212 Extended System Cable

Cable Technical Specifications

• Brand: Schneider Electric
• Model: 140XTS00212
• Product Type: Extended length pre-terminated cable
• Cable Length: 12.1 feet (3.7 meters) total reach
• Current Capacity: 8A maximum continuous current
• Voltage Rating: 300V AC/DC working voltage maximum
• Conductor Size: 22 AWG stranded copper wires
• Signal Integrity: < 2dB attenuation at 10MHz
• Propagation Delay: 5.2 ns/m maximum
• Characteristic Impedance: 100Ω ±15%

Electrical Performance Features

• DC resistance: < 55 Ω/km at 20°C temperature
• Insulation resistance: > 100 MΩ·km minimum
• Capacitance between conductors: < 120 pF/m
• Dielectric strength: 1500V AC for one minute
• Crosstalk attenuation: > 40 dB at 1MHz
• Shielding effectiveness: > 60 dB at 30MHz
• Surge withstand: 1kV 1.2/50μs wave

Physical Construction Details

• Jacket Color: Standard black for industrial use
• Jacket Material: PVC with UV stabilization
• Minimum Bend Radius: 6x cable diameter
• Tensile strength: 100N maximum pulling force
• Crush resistance: 200 N/cm minimum rating
• Flex life: 15,000 bend cycles minimum
• Flame rating: UL 1581 VW-1 compliant

Environmental Specifications

• Operating Range: -40°F to 221°F (-40°C to 105°C)
• Storage Range: -40°F to 221°F (-40°C to 105°C)
• Humidity Tolerance: 95% non-condensing maximum
• Oil resistance: Withstands IRM 903 oil exposure
• Chemical resistance: Acids, alkalis, and solvents
• Weather resistance: UV protected for outdoor use

Connector System Details

• Quantum I/O connector: 50-position keyed design
• SUB-D connector: 50-pin high-density layout
• Contact plating: 0.76μm gold over 1.27μm nickel
• Mating cycles: 500 minimum insertion/withdrawal
• Contact resistance: < 15 mΩ initial
• Insulation resistance: > 5000 MΩ between contacts
• Dielectric strength: 1000V RMS contact to shell

Shipping & Package Information

• Individual 140XTS00212 cable in protective packaging
• Package dimensions: 12.60" × 11.81" × 1.77" (32.0 × 30.0 × 4.5 cm)
• Shipping weight: 2.222 pounds (1.008 kg)
• Express delivery via FedEx, UPS, and DHL available
• Complete 12-month product warranty coverage

Installation & Application Expertise

• What advantages does the extended 3.7-meter length provide in control cabinet layouts?
• This longer reach allows flexible module placement and easier access for maintenance in crowded enclosures.
• How does cable length affect signal quality and what compensation is built in?
• Proper impedance control and shielding maintain signal integrity across the entire 3.7-meter distance.
• What installation techniques prevent damage during cable routing and connection?
• Use gradual bends, avoid sharp edges, and provide strain relief at both connection points for longevity.
• How does the environmental rating suit different industrial application scenarios?
• The wide temperature range and chemical resistance make this cable suitable for harsh factory environments.
• What testing procedures verify cable performance after installation?
• Continuity testing and insulation resistance checks ensure proper installation and long-term reliability.
