CA202 Piezoelectric Accelerometer: Heavy-Duty Vibration Monitoring

Product Description

The CA202 piezoelectric accelerometer from Vibro Meter delivers reliable vibration measurement in demanding industrial environments. Built with a hermetically sealed stainless-steel case and integral cable protected by a flexible stainless-steel hose, this sensor is perfect for harsh conditions and potentially explosive atmospheres. Its symmetrical shear-mode design ensures accurate readings with excellent stability.

Key Features

High Sensitivity: 100 pC/g for precise measurements.

Wide Frequency Range: 0.5 to 6000 Hz.

Extended Temperature Operation: -55°C to +260°C.

Explosion-Proof Options: Available in Ex versions for hazardous areas.

Robust Construction: Hermetically welded, resistant to humidity, oil, and dust.

Technical Specifications

Brand: Vibro Meter

Model: CA202 (Standard and Ex versions available)

Measuring Range: 0.01 to 400 g peak

Accuracy: ±1% (0.01-20 g), ±2% (20-400 g)

Output Signal: Charge output, 2-pin system

Operating Temperature: -55°C to +260°C (sensor), -55°C to +200°C (cable)

Frequency Response: 0.5 to 6000 Hz (±5%)

Resonant Frequency: >22 kHz

Weight: 250 g (sensor), 135 g/m (cable)

Installation Guide

Mount using four M6 x 35 Allen screws and M4 spring-lock washers. Tightening torque: 15 N•m (11.1 lb-ft). Ensure proper grounding and cable strain relief for optimal performance.

Compatibility

Works with IPC70x series signal conditioners for signal processing. Compatible with standard vibration monitoring systems.

Certification & Safety

ATEX Certified Ex versions available for use in explosive atmospheres. All versions feature internal case insulation and meet industrial safety standards.

Packaging & Warranty

Package Includes: CA202 accelerometer, integral cable with protection hose, mounting hardware.

12-Month Warranty included. Fast shipping via FedEx, UPS, or DHL.
