Allen-Bradley 20F11NC072JA0NNNNN | PowerFlex 753 37kW AC Drive

Looking for precise motor control? This Allen-Bradley drive delivers. The 20F11NC072JA0NNNNN model provides 37 kW (50 HP) of reliable power. It works with common 400V AC 3-phase systems. Ideal for improving efficiency in pumps, fans, and machine tools.

Complete Technical Details

Brand & Model: Allen-Bradley 20F11NC072JA0NNNNN
Product Series: PowerFlex 753 Variable Frequency Drive (VFD)
Output Power: 37 kW (Normal Duty), 30 kW (Heavy Duty)
Output Current: 72 Amperes
Input Voltage: 400 Volts, 3-Phase, 50/60 Hz
DC Bus Voltage: 540 V DC
Frame Size: Frame 4
Enclosure: Open Type (must be installed in a cabinet)
Cooling: Air Cooled (Internal Fan)
Braking: Internal Dynamic Braking Transistor (External resistor not included)
Standard Features: Embedded Digital/Analog I/O, EMI/RFI Input Filter, Common Mode Jumper Installed
Expansion Slots: 3 Slots for Safety, Feedback, or Communication Cards
User Interface: No built-in keypad (requires separate HIM or software)
Mounting: Vertical on panel
Approximate Weight: 27.22 kg (60 lbs)

Simple Setup Instructions

1. Mount this 20F11NC072JA0NNNNN drive vertically inside a clean, dry electrical cabinet.
2. Connect the 3-phase 400V AC power supply to the main input terminals.
3. Wire your 3-phase motor to the drive's output terminals (T1/U, T2/V, T3/W).
4. Use the embedded I/O terminals for basic control signals like Run/Stop.
5. Add optional cards to the slots if you need safe torque off, encoder feedback, or network communication (like Ethernet/IP).
6. Configure motor parameters using a connected computer with programming software or a removable keypad.
7. Always perform initial testing at low speed without the mechanical load connected.

Frequently Asked Questions (FAQ)

What motors is this drive rated for?
It is rated for a 37kW (about 50 HP) motor under normal duty cycles. For applications where the motor runs at full load continuously (heavy duty), use it with a 30kW (40 HP) motor.

Can I add network communication later?
Yes. The three option slots allow you to add communication cards (like Ethernet/IP or DeviceNet) at any time. You don't need to buy a different drive model.

Why is there no braking resistor included?
The internal transistor can handle typical deceleration. An external resistor is only needed for very fast stops or high-inertia loads to dissipate the extra energy as heat.

How do I program it without a keypad?
You can use Rockwell Automation's free Connected Components Workbench software on a Windows PC, connected via a USB cable. A separate handheld HIM is also available.

Is the input filter sufficient for my facility?
The built-in filter meets common industrial standards. In facilities with very sensitive equipment, consult an engineer. You may need an additional or higher-grade filter at the main power entry point.

Package & Warranty Information

You will receive one new Allen-Bradley 20F11NC072JA0NNNNN AC Drive. We offer a straightforward 12-month warranty from your purchase date. This covers any failure in materials or workmanship under normal use.

Shipping Options

We pack your order with care and ship it fast. Choose from our reliable partners: FedEx, UPS, or DHL during checkout for global delivery.
