Bently Nevada Standoff Probe Housing Assembly

Introducing the 21000-16-10-15-029-03-02 with integrated 1.5-inch standoff adapter. This professional housing assembly provides optimal probe positioning with 2.9-inch penetration depth. The 21000-16-10-15-029-03-02 combines precision engineering with hazardous area safety certifications. Perfect for applications requiring precise standoff distance and reliable performance.

Standoff Configuration Features

• Standoff Adapter: 1.5 inches (38 mm) included
• Probe Penetration: 2.9 inches optimal depth
• Probe Type: 3300 XL 8mm high-performance
• Cable Length: 1.0 meter standard size
• Mounting Thread: 3/4-14 NPT industry standard
• Penetration Range: 13 mm adjustment capability

Physical Dimensions

• Visible Probe Length: 17.0 inches maximum
• Total Extension: 32.9 inches full reach
• System Weight: 1.1 kg without fittings
• Housing Material: Durable aluminum body
• Sleeve Construction: 304 stainless steel
• Counter Bore: Recommended for 1.0-2.0 inch penetration

Complete Package Contents

• Reverse mount proximity probe installed
• 1.5-inch standoff adapter included
• Dome cover with screw fastening
• Multiple O-rings for sealing
• Threaded conduit connection ports
• Complete thread seal set

Fittings & Accessories

• One 3/4-14 NPT plug for sealing
• One 3/4-14 to 1/2-14 NPT reducer
• Universal cable seal grip system
• Three size grommets for cable management
• 1/8 to 3/16 inch cable grommet
• 1/4 to 5/16 inch cable grommet
• 5/16 to 3/8 inch cable grommet

Safety & Compliance

• CSA Certified: Explosion-proof rating
• Class 1 Division 1: Groups C and D
• Class 2 Division 1: Groups E, F, G
• Enclosure Type 4: Weather protection
• API 670 Compliant: Industry standard
• RoHS Compliant: Environmental directive

Installation Guidelines

• Counter bore machine case for 1.0-2.0 inch penetration
• Add sleeve support for penetration over 300 mm
• Use flag label for probe identification
• Ensure proper thread engagement
• Verify O-ring placement before operation
• Check cable seal grip tightness

Model Configuration Details

• 21000 - Housing Assembly Base
• 16 - 3300 XL 8mm Probe
• 10 - 1.0 Meter Cable
• 15 - 1.5 Inch Standoff
• 029 - 2.9 Inch Penetration
• 03 - Complete Fittings
• 02 - 3/4-14 NPT Thread

Service & Delivery

• 12-month product warranty
• FedEx Express delivery
• UPS Worldwide service
• DHL International shipping
• Fast order processing
• Real-time tracking available

Technical Questions

When should I use the standoff adapter?

Use the 1.5-inch standoff when you need precise probe positioning away from the mounting surface.

What is counter boring and when is it needed?

Counter boring machine cases reduces probe side view effects for 1.0-2.0 inch penetration depths.

How do I prevent probe resonance?

Add sleeve support near the probe for penetration lengths exceeding 300 mm (12 inches).

What temperature ratings apply?

T5 rating for -50°C to +40°C, T4 rating for -50°C to +80°C ambient temperatures.

Can I see the probe serial number after installation?

Yes, flag labels display probe information when only small cable sections remain visible.
