ABB TZIDC-120 Fieldbus Positioner with ATEX Certification

Upgrade to smart fieldbus control. This ABB V18347-2041150001 positioner connects directly to FOUNDATION Fieldbus networks. It is perfect for hazardous areas. The rugged aluminum case protects against harsh weather and dust. It delivers precise valve control with a clear mechanical indicator. Simplify your process automation with this advanced device.

Key Product Details

• Complete Part Number: V18347-2041150001
• Brand & Series: ABB TZIDC-120 Series
• Communication: FOUNDATION Fieldbus Input
• Safety Certification: ATEX EEx ia IIC T6
• Enclosure Rating: IP65 / NEMA 4X
• Operating Temperature: -40°C to +85°C
• Mounting: Fits linear and rotary actuators
• Air Connection: Thread 1/4-18 NPT
• Electrical Connection: M20 x 1.5 cable gland
• Unit Weight: 1.7 kg

Model Code Breakdown: V18347-2041150001

Every digit in the suffix 2041150001 has a meaning.

Core Configuration:

• V18347: TZIDC-120 series base model.
• 20: Aluminum case with mechanical position indicator.
• 4: Input is FOUNDATION Fieldbus protocol.

Safety & Output:

• 1: ATEX explosion protection rating (EEx ia IIC T6).
• 1: Single acting, fail-safe output action.
• 5: Connections: M20 cable and 1/4-18 NPT air.

Options & Finish:

• 0: No shutdown function module.
• 00: No digital feedback kit installed.
• 1: Standard black (RAL 9005) paint finish.

Performance & Environmental Specs

• Supply Air Pressure: 1.4 to 7 bar (typical).
• Air Consumption: Very low, under 0.04 kg/h.
• Relative Humidity: Up to 95% during operation.
• Housing Material: Painted aluminum for durability.
• Response Time: Fast and stable for precise control.

Warranty & Shipping

We stand behind our products. You receive a solid 12-month warranty against defects. Our team provides full support. We ship globally using reliable carriers like FedEx, UPS, and DHL. Tracking details are provided for every order.

Frequently Asked Questions

What does the ATEX EEx ia IIC T6 rating mean?

It means this V18347-2041150001 positioner is intrinsically safe. You can use it in Zone 0/1 hazardous areas with specific gas groups.

Can I mount this on any valve actuator?

It mounts to linear actuators following DIN/IEC 534/NAMUR. It also fits rotary actuators per VDI/VDE 3845.

Does it need a separate power supply?

No. For FOUNDATION Fieldbus models, power comes from the fieldbus segment itself.

Is the mechanical position indicator easy to read?

Yes. It has a clear, direct-reading scale for quick visual checks on-site.

What is the lead time for this model?

Stock items ship fast, usually within 1-3 business days after order confirmation.
