GE Fanuc IC200MDL140 AC Input Module
Monitor AC signals with the IC200MDL140 input module. This Versamax series component offers 8 discrete inputs. Works with 120V AC signals. Built-in power. Easy to install. Perfect for industrial sensors and switches.
Key Benefits
- AC Inputs: 8 discrete inputs for 120V AC signals.
- No External Power: Draws power from backplane.
- Clear Status: LED indicators for each input.
- Easy Installation: Snap-in design for quick setup.
- Hot Swappable: Replace without powering down.
Technical Specifications
| Brand | GE Fanuc |
| Series | Versamax |
| Model | IC200MDL140 |
| Product Type | Discrete Input Module |
| Input Points | 8 discrete inputs |
| Voltage Rating | 120V AC |
| Operating Range | 0-132V AC |
| On-State Range | 70-132V AC |
| Off-State Range | 0-20V AC |
| Power Consumption | 55mA @ 5V DC |
| Input Impedance | 8.6 kΩ @ 60Hz |
| Dimensions | 110 x 66.8 x 50.0 mm |
Installation Guide
Install in Versamax I/O carrier. Connect AC field devices. No external power needed. Check LED status lights. Use hot-swap capability.
Compatibility
Works with all Versamax systems. Fits standard Versamax carriers.
Warranty
Complete 12-month warranty provided.
Shipping
Fast worldwide delivery via FedEx, UPS, and DHL.
Frequently Asked Questions
How many inputs does this module have?
It has 8 discrete AC input points.
What voltage does it accept?
It works with 120V AC signals (0-132V AC range).
Does it need external power?
No, it draws power from the Versamax backplane.
What are the LED indicators for?
They show the on/off status of each input channel.
Can I replace it while powered on?
Yes, it supports hot insertion and removal.
