ICS Triplex T8312 Expander Interface Adapter

The T8312 Expander Interface Adapter from ICS Triplex enables seamless system expansion for industrial control applications. This robust interface module connects controller chassis with multiple expander units. It maintains reliable communication between processor and expansion systems. The adapter supports flexible configurations for growing operational needs. ICS Triplex designed this component for critical control environments requiring high availability.

Technical Specifications & Models

• Brand: ICS Triplex | Model: T8312 Expander Interface Adapter
• Operating Voltage: 24 VDC ±10% with reverse polarity protection
• Current Consumption: 85 mA maximum at 24 VDC
• Operating Temperature: 0°C to +60°C (32°F to 140°F)
• Storage Temperature: -40°C to +85°C (-40°F to 185°F)
• Relative Humidity: 5% to 95% non-condensing
• Communication Speed: 1.5 Mbps data transfer rate
• Isolation Voltage: 500 VDC between chassis
• Vibration Resistance: 2g from 10-500 Hz operational
• Shock Tolerance: 15g for 11 ms duration
• Weight: 0.65 kg (1.43 lbs) per unit
• Certifications: ATEX, IECEx, HazLoc compliant

Available Models & Configuration

• T8312/4: Supports connection of up to four expander chassis
• T8312/7: Manages communication with seven expander units
• Controller chassis DIP switch must always set to position #1
• Expander chassis IDs configure sequentially from 2 to 8
• Additional adapters enable system expansion beyond eight units
• Software recognizes expanded chassis as IDs 9 through 15

Installation & Setup Guidelines

• Mount the adapter securely in the controller chassis slot
• Set controller DIP switch to position 1 before power-up
• Configure expander chassis IDs sequentially starting from 2
• Use high-quality shielded cables for all inter-chassis connections
• Verify proper grounding between all connected chassis
• Complete software configuration before system operation

System Integration Features

• Enables scalable control system architecture
• Maintains real-time data synchronization between chassis
• Provides electrical isolation between controller and expanders
• Supports hot-swapping capabilities for maintenance
• Ensures data integrity through error checking mechanisms
• Facilitates system diagnostics and status monitoring

Packaging & Shipping Details

• Includes one ICS Triplex Expander Interface Adapter unit
• Comprehensive installation and configuration manual
• All necessary mounting hardware and connectors included
• Industrial-grade protective packaging materials
• Worldwide express shipping via FedEx, UPS, and DHL
• Order processing within 24 hours for in-stock items

Warranty & Support Services

• 12-month comprehensive warranty from date of purchase
• Technical support available for installation guidance
• Replacement service for defective components
• Extended warranty options for critical applications
• Documentation and software configuration assistance

Professional FAQ

• What is the maximum distance between controller and expander chassis?
• The system supports distances up to 100 meters using standard cables
• Can I mix T8312/4 and T8312/7 adapters in the same system?
• No, you should use identical adapter models within a single system
• What happens if two expander chassis have the same ID number?
• The system will generate a configuration error during initialization
• Is special software required to configure the adapter settings?
• Yes, you need the ICS Triplex configuration software tool
• Can the adapter operate in high-electrical-noise environments?
• Yes, it features enhanced noise immunity and shielding protection
