GE Fanuc IC200MDD845 I/O Module | VersaMax Series

The IC200MDD845 from GE Fanuc (now Emerson Automation) provides versatile 24-point discrete I/O capability. This mixed module combines 16 DC inputs with 8 isolated relay outputs for flexible control applications.

Key Technical Specifications

• Brand: GE Fanuc / GE Intelligent Platforms
• Model: IC200MDD845
• Type: 24-Point Combination I/O Module
• Input Channels: 16 (24 VDC Positive Logic)
• Output Channels: 8 Form A Relay Contacts
• Output Rating: 2.0A @ 5-265 VAC/5-30 VDC
• Backplane Current: 270 mA maximum
• Input Voltage: 18-30 VDC (24 VDC nominal)

Input Specifications

• 16 positive logic DC input channels
• On-state current: 2.0-5.5 mA
• Off-state current: 0-0.5 mA
• Response time: 0.5 ms ON, 10 ms OFF
• Individual LED indicators for each channel

Output Specifications

• 8 individually isolated Form A relay outputs
• Contact rating: 2.0A maximum
• Voltage range: 0-125 VDC / 0-265 VAC
• Frequency: 47-63 Hz for AC operation
• Minimum load: 10 mA per point

Installation & Operation

• Requires IC200CHS series carrier base
• OK LED indicates backplane power status
• Channel LEDs show actuation state
• External power needed for additional loads
• Compact dimensions: 110 x 66.8 x 50 mm

Packaging & Shipping

• Includes one GE Fanuc IC200MDD845 I/O module
• International shipping via FedEx, UPS, and DHL available
• Complete tracking information provided with all orders
