Schneider Electric Modicon TSXP572634 Unity Processor

The Schneider Electric TSXP572634 is a high-performance Unity processor for complex automation. This Modicon CPU manages large-scale control systems with extensive I/O requirements. It supports a total capacity of 1024 discrete input and output points. The TSXP572634 also provides control for 80 analogue signals for process applications.

Core Processor Specifications

• Brand: Schneider Electric
• Model: TSXP572634
• Product Line: Modicon Premium/Quantum (Unity Platform)
• Product Type: Central Processing Unit (CPU)
• Discrete I/O Capacity: Up to 1024 Points
• Analogue I/O Capacity: Up to 80 Points
• Communication Port: 10BASE-T/100BASE-TX Ethernet
• Module Format: Double-width Module
• Current Consumption: 1650 mA @ 5V DC
• Processor Weight: 0.042 kg

System Architecture & Rack Configuration

• Maximum Number of Racks: 8 Racks (12 slots each) or 16 Racks (4/6/8 slots)
• Maximum Total Slots: Up to 128 I/O and Special Module Slots
• Backplane Communication: High-speed proprietary bus
• Memory Capacity: Suitable for large and complex control programs
• Scan Time: Dependent on program size and I/O configuration
• Supported Programming Languages: Unity Pro (LD, FBD, IL, SFC, ST)

Environmental & Physical Ratings

• Operating Temperature: 0°C to +60°C (32°F to 140°F)
• Storage Temperature: -25°C to +70°C (-13°F to 158°F)
• Operating Humidity: 5% to 95% (Non-condensing)
• Ingress Protection (IP): IP20 (For indoor, dry environments)
• Vibration & Shock: Compliant with industrial automation standards
• Mounting: Designed for standard Modicon rack

Communication & Network Features

• Integrated Ethernet Port: 10/100 Mbps, TCP/IP protocol support
• Network Services: Modbus TCP, FTP, Web Server capabilities
• Additional Ports: May include serial ports for legacy devices
• Real-Time Clock: Typically included for time-stamping functions
• Data Retention: Battery-backed or non-volatile memory for program

Installation & Power Guidelines

• Install the CPU in the leftmost slot of the main rack (slot 0).
• Ensure the rack power supply can deliver the required 5V DC current.
• Use the built-in Ethernet port for programming and HMI connectivity.
• Plan your I/O rack configuration within the 8 or 16 rack limit.
• Allow sufficient space around the module for proper air circulation.
• Connect a compatible programming laptop with Unity Pro software.
• Verify all expansion rack cables are securely connected.

Packaging & Shipping Information

• Package Contents: 1 x TSXP572634 CPU Module
• Accessories: May include battery, connector covers, or documentation
• Package Protection: Anti-static packaging and cushioning
• Shipping Methods: FedEx, UPS, DHL Express services available
• International Shipping: Available to most global destinations
• Order Lead Time: Subject to stock availability

Warranty & Technical Support

• Standard Warranty: 12 months from the invoice date
• Warranty covers factory defects in materials and component workmanship.
• Support includes assistance with configuration and troubleshooting.
• Always refer to the official Unity Pro manual for programming details.

Frequently Asked Questions (FAQ)

• What is the main advantage of the 1024 discrete I/O capacity?

This high capacity allows you to control very large machines or entire multi-station production lines with a single CPU, reducing system complexity and cost compared to using multiple smaller PLCs.

• Can I connect this CPU to a standard office network?

Yes, the integrated 10/100 Ethernet port uses standard TCP/IP. You can connect it to a network switch for programming, SCADA communication, and data collection alongside other network devices.

• What does "80 analogue I/O" capacity mean in practice?

It means the processor can manage the data from up to 80 analogue channels. These could be temperature sensors (4-20mA), pressure transmitters, or analog control valves, making it ideal for process control applications.

• Is the IP20 rating sufficient for a factory floor?

IP20 protects against finger-sized objects but not dust or water. This CPU must be installed inside a protected control cabinet (which should have a higher IP rating) on the factory floor, not directly exposed.

• How do I expand the system to 16 racks?

You use special remote I/O adapter modules and communication cables (like FBP). The CPU manages these remote racks as part of its total I/O count, allowing you to distribute I/O points across a wider area.
