Schneider Electric TSXP571634: Powerful Unity Automation Processor

Take control with the Schneider Electric TSXP571634 Unity Processor. This robust CPU for the Modicon series handles large-scale automation. It manages 512 discrete I/O and 24 analog I/O points. Perfect for complex machines and process control. It offers reliable performance with flexible memory optionss

Technical Data

Brand: Schneider Electric
Model: TSXP571634
Product Line: Modicon / Unity
Type: Automation Processor (CPU)
Discrete I/O Capacity: 512 I/O
Analog I/O Capacity: 24 I/O
Application Channels: 8
Memory (with PCMCIA): 224 kB Program, 96 kB Data
Memory (without PCMCIA): 96 kB Program & Data
Input Voltage: 5 VDC
Current Consumption: 1650 mA
Protection Class: IP20
Operating Temperature: 0°C to 60°C
Storage Temperature: -25°C to 70°C
Operating Altitude: 0 to 2000 m
Weight: 0.74 kg

Installation Guide

Install the processor in a protected IP20 enclosure (control cabinet).
Ensure a stable 5VDC power supply is provided.
Mount securely on a DIN rail according to the manual.
Connect I/O modules and communication cables to the backplane.
Allow for proper ventilation and adhere to the specified temperature range.
Always follow the official Schneider Electric installation and wiring guidelines.

Compatibility

This Unity Processor is designed for the Schneider Electric Modicon / Unity Premium automation platform. It is compatible with the corresponding range of discrete, analog, and special function I/O modules. Verify system compatibility for your specific application.

Packaging List

1 x Schneider Electric TSXP571634 Unity Processor Unit.
Documentation may be included or provided separately.

Warranty & Support

We provide a full 12-month warranty from the purchase date, covering any defects in materials or manufacturing.

Shipping

We ship internationally via FedEx, UPS, and DHL for fast and reliable delivery. Shipping options and costs are available at checkout.

Note: Specifications are subject to the official Schneider Electric documentation. Always consult the technical guide for your specific application.
