GE Fanuc 24VDC Input Module IC200MDL650 | VersaMax Series
Manufacturer:
GE
Product No.:
IC200MDL650A
Condition:
In Stock
Product Type:
Discrete Input Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Pouzdani globalni dobavljač dijelova za automatizaciju
Nudimo širok asortiman industrijskih rezervnih dijelova za automatizaciju na skladištu. Svi proizvodi dolaze s 12-mjesečnim jamstvom i 30-dnevnim povratom novca zbog problema s kvalitetom.
Emerson IC200MDL650 24VDC Input Module | VersaMax Series
The IC200MDL650 from Emerson's VersaMax series delivers high-density 32-point input capability. This advanced DC input module provides exceptional flexibility with four isolated groups. It handles both positive and negative logic configurations for diverse industrial applications.
Brand & Model Information
- Brand: Emerson Automation (formerly GE Intelligent Platforms)
- Series: VersaMax I/O
- Model: IC200MDL650
- Product Type: 32-Point Discrete Input Module
Key Technical Specifications
- Input Channels: Thirty-Two (32) points in four groups
- Nominal Input Voltage: 24 VDC
- Operating Voltage Range: 0 - 30 VDC
- Input Impedance: 10K Ohms typical
- On-State Voltage: 15-30 VDC
- Off-State Voltage: 0-5 VDC
- Response Time: 0.5 ms maximum
Isolation & Group Configuration
- Group Isolation: 250 VAC continuous; 1500 VAC for 1 minute
- Number of Groups: Four isolated groups (8 points each)
- Channels per Group: Eight individually configurable points
- Each group supports positive or negative logic wiring
Current Characteristics & Filtering
- On-State Current: 2.0 - 5.5 mA
- Off-State Current: 0 - 0.5 mA
- Configurable Filter Times: 0 ms, 1.0 ms, and 7.0 ms
- Default Filter: 1.0 ms for optimal noise immunity
Power Requirements & Indicators
- Backplane Power: 5VDC, 50 mA maximum consumption
- External Power: Not required - powered through backplane
- LED Indicators: One OK LED and thirty-two channel status LEDs
Installation & Compatibility
- Standard DIN rail mounting (horizontal or vertical orientation)
- Compatible with pushbuttons, limit switches, and proximity sensors
- Integrates seamlessly with VersaMax I/O platform
- Supports various industrial communication protocols
Packaging & Shipping
- Packaging Includes: One IC200MDL650 module
- Global shipping via FedEx, UPS, and DHL available
Frequently Asked Questions
- How many input points does it have? The module features thirty-two discrete input points.
- What isolation does it provide? It offers four isolated groups with 250VAC continuous isolation.
- Does it support both logic types? Yes, it handles both positive and negative logic configurations.
