GE Fanuc Versamax IC200PWR201 Compact Power Supply
The IC200PWR201 module is a compact DC power supply for Versamax systems. It provides reliable 5V and 3.3V power for your PLC, I/O modules, and controllers. Perfect for space-limited panels.
Quick Overview
- Input: 9.6 - 15V DC (12V Nominal)
- Output: 5V DC & 3.3V DC
- Total Power: 11 Watts
- Protection: Short Circuit, Overload, Reverse Polarity
- Compact Size: Fits small spaces easily
Complete Technical Specifications
- Brand: GE Fanuc
- Series: Versamax
- Model: IC200PWR201
- Product Type: Non-Isolated Power Supply
- Input Voltage Range: 9.6 - 15V DC
- Nominal Input Voltage: 12V DC
- Input Power: 11 Watts
- Inrush Current: 25A @ 12V DC, 30A @ 15V DC
- Output Voltage 1: 5V DC
- Output Voltage 2: 3.3V DC
- 3.3V Output Current: 0.25A max
- 5V Output Current: 1.25A max (1.5A total minus 3.3V used)
- Total Output Current: 1.5A maximum
- Holdup Time: 10 milliseconds
- Isolation: Non-Isolated
- Extended Power: Not Supported
- Dimensions: 49mm x 133.4mm x 39mm (1.93" x 5.25" x 1.54")
Application & Installation
Use the IC200PWR201 as the main power source for Versamax I/O stations. It powers CPUs, NIUs, and backplane devices. Mounts easily on DIN rails. Works as supplementary power in larger systems.
Expert FAQ
Q1: What is the maximum current for the 3.3V output?
A1: The 3.3V output provides up to 0.25A maximum current.
Q2: Can I use this with a 24V system?
A2: No, the input range is 9.6-15V DC. Use a different model for 24V systems.
Q3: What happens if I wire the power backwards?
A3: Reverse polarity protection keeps the module safe from incorrect wiring.
Q4: Is this power supply isolated from ground?
A4: No, this is a non-isolated power supply module.
Q5: Can I add extra power with a booster?
A5: No, this model does not support extended power configurations.
