Allen-Bradley 22B-E4P2N104 PowerFlex 40 Drive - 3HP 600V Industrial VFD

Key Benefits of This Drive

• Precision Control - Sensorless Vector technology for accurate speed regulation
• Space-Saving Design - Zero stacking installation minimizes panel space
• Advanced Features - Built-in PID, Timer, and Logic functions
• Flexible Mounting - DIN rail or panel installation options
• Download Manual: PowerFlex 40 User Manual

Technical Specifications

• Input: 460-600V AC, 3-Phase
• Output: 4.2A, 3HP (2.2kW), 0-575V AC
• Dimensions: 10.24" H × 5.12" W × 7.09" D
• Enclosure: IP20/NEMA Open
• Control Methods: Sensorless Vector & V/Hz
• Communication: RS-485 (Modbus RTU)
• Braking: IGBT brake included
• Operating Temp: 0°C to 60°C (32°F to 140°F)

Product Details

• Brand: Allen-Bradley
• Model: 22B-E4P2N104 (PowerFlex 40 Series)
• UPC: 820919147562
• Warranty: 12-month coverage

Expert FAQs

1. What protection devices are needed? - Requires input fuses or circuit breaker
2. Can multiple drives be stacked together? - Yes, zero stacking minimizes space
3. Is this suitable for residential use? - No, industrial environments only
4. What's the frequency output range? - 0-400Hz programmable output
5. Does it include dynamic braking? - Yes, with built-in IGBT brake

Complete Documentation

For full installation and programming details, download the PowerFlex 40 User Manual.
