Schneider Electric 170INT11003C: Robust Industrial Communication Adapter

• Connect up to 254 devices in a single reliable network
• Extend your system over 12.8 km cable distance
• Fail-safe ring topology ensures continuous operation
• Industrial-grade protection against electrical interference

Product Overview

The Schneider Electric 170INT11003C delivers reliable industrial communication. This Modicon Momentum adapter creates robust networks. It supports ring topology for maximum reliability. Perfect for large-scale automation systems requiring stable data exchange.

Technical Specifications

• Brand: Schneider Electric
• Model: 170INT11003C
• Product Line: Modicon Momentum
• Adapter Type: Communication Module
• Data Rate: 500 kbit/s
• Network Topology: Ring
• Max Devices: 254 per segment
• Cable Distance: 12,800 meters
• Connectors: Two SUB-D 9-pin
• Protection Class: IP20
• EMC Resistance: 10 V/m
• ESD Protection: 4 kV/8 kV
• Weight: 0.07 kg
• LED Indicators: Status monitoring
• Safety Feature: Fail-safe operation
• Operating Voltage: 24V DC standard

Key Features

Large network capacity. Long-distance capability. Ring topology reliability. Electrical noise immunity. Compact and lightweight. Easy status monitoring.

Installation Guide

Use ring network configuration. Connect both SUB-D ports properly. Ensure cable length within limits. Check LED indicators after installation. Verify network communication.

Application Areas

Large factory automation. Process manufacturing. Water treatment plants. Power distribution systems. Mining operations. Infrastructure monitoring.

Shipping & Warranty

Fast global delivery via FedEx, UPS, DHL. Includes 12-month product warranty. Technical assistance available.

Frequently Asked Questions

What advantage does ring topology provide?

Ring configuration maintains network communication even if one connection fails, ensuring system reliability.

How many devices can I network together?

You can connect up to 254 devices in a single segment, suitable for large industrial installations.

What is the maximum distance between devices?

The system supports cable runs up to 12.8 kilometers between devices for widespread facilities.

How does it handle electrical interference?

Built-in protection against electromagnetic fields up to 10 V/m and electrostatic discharge up to 8 kV.

Is network expansion easy with this adapter?

Yes, the modular design allows easy addition of devices up to the maximum limit without system shutdown.
