Schneider Electric 990NAD21130 Modbus Plus Drop Cable

The Schneider Electric 990NAD21130 provides reliable connectivity for industrial networks. This 6-meter drop cable works with Modicon Quantum and other automation platforms. You can trust this cable for stable communication in various factory environments.

Complete Technical Specifications

• Brand & Manufacturer: Schneider Electric
• Model Number: 990NAD21130
• Product Line: Modicon Quantum Series
• Cable Type: Modbus Plus Network Drop Cable
• Cable Length: 6 meters (19.7 feet)
• Connector Type: 1x Male SUB-D 9 pin (elbowed design)
• Cable End: Free end for local site tap connection
• Temperature Range: 0°C to 60°C operating (32°F to 140°F)
• Humidity Tolerance: Up to 80% RH (non-condensing)
• Altitude Rating: 1000 meters above sea level maximum
• Cable Weight: 0.53 kg (1.17 lbs)
• Shielding: Standard industrial-grade shielding for noise immunity
• Flexibility: Medium flexibility for easy routing in control panels
• Voltage Rating: Suitable for standard network communication voltages

Compatible Products & Systems

• Direct Compatibility: 990NAD23020, 990NAD23000, 490NRP25300
• Additional Compatibility: 990NAD23010, 990NAD23021, NWBP85002
• Controller Compatibility: STBNMP2212, 140CPU43412U, 140CPU31110
• Platform Compatibility: Modicon Momentum and Premium automation
• System Compatibility: Advantys STB distributed I/O solutions
• Drive Compatibility: Lexium 15 drive systems
• Primary Platform: Modicon Quantum automation platform

Installation & Environmental Guidelines

• Connect the male SUB-D 9 connector to your communication module securely
• Use the free cable end for tapping into local network connections
• Maintain ambient temperature within the 0°C to 60°C range for optimal performance
• Ensure installation environments stay below 80% relative humidity
• Follow proper cable management practices to avoid sharp bends
• Keep the cable away from high-voltage power lines to prevent interference
• Verify all connections match your network configuration requirements

Packaging & Shipping Information

• Single Unit Package: Includes one 990NAD21130 drop cable
• Package Dimensions: 24.8cm L × 20.9cm W × 2.5cm H
• Package Weight: 362 grams (12.8 ounces)
• Bulk Package Option: 25 units per master carton available
• Bulk Carton Size: 40cm L × 30cm W × 30cm H
• Bulk Carton Weight: 9.62 kg (21.2 lbs)
• Shipping Methods: We ship via FedEx, UPS, and DHL worldwide
• Quality Warranty: All products include 12-month quality assurance

Expert Questions & Answers

What is the main purpose of this specific drop cable?

• This cable establishes Modbus Plus network connections between devices. It links communication modules to network taps in industrial control systems.

Can I use this cable with non-Schneider Electric equipment?

• The cable has a standard SUB-D 9 connector that may physically fit other devices. However, we only guarantee performance with compatible Schneider systems listed above.

How does temperature affect this cable's performance?

• Extreme temperatures outside the 0-60°C range can degrade insulation materials. This may lead to signal integrity issues over time in harsh environments.

What is the practical maximum distance between devices?

• While this cable is 6 meters long, total network distance depends on your entire setup. Consider all cable segments and device specifications for reliable communication.

How should I store spare cables before installation?

• Keep cables in their original packaging in dry conditions below 50°C. Avoid placing heavy objects on the packages to prevent connector damage.
