Bently Nevada 330703-000-060-10-11-05 | 11mm Proximity Probe
UBEST – Сенімді Ғаламдық Автоматтандыру Бөліктерінің Жеткізушісі
Бізде қорда бар өнеркәсіптік автоматтандыру қосалқы бөлшектерінің кең таңдауы бар. Барлық өнімдерге 12 айлық кепілдік беріледі және сапа мәселелері бойынша 30 күндік қайтару ұсынылады.
Bently Nevada 330703 11mm Proximity Probe
Brand new Bently Nevada 330703-000-060-10-11-05 proximity probe. 11mm metric design with M14 thread. Complete with multiple agency approvals. Factory sealed with warranty.
Complete Part Number Details
- 330703 - 3300 XL 11mm Probe Base Model
- 000 - 00 mm Unthreaded Length
- 060 - 60.0 mm Overall Case Length
- 10 - 1.0 Meter Total Cable Length
- 11 - ClickLoc Connector with FluidLoc Cable
- 05 - Multiple Agency Approvals Included
Technical Specifications
- Brand: Bently Nevada
- Full Part Number: 330703-000-060-10-11-05
- Probe Diameter: 11 mm
- Thread Type: M14 x 1.5 Metric
- Case Length: 60.0 mm
- Cable Length: 1.0 Meter
- Connector Type: Miniature Coaxial ClickLoc
- Cable Type: FluidLoc Triaxial
- Probe Resistance: 5.9 ± 0.5 Ohms
- Tip Material: Polyphenylene Sulfide (PPS)
- Case Material: 304 Stainless Steel
- Max Torque: 63.3 N•m (560 in•lb)
- Recommended Torque: 21.1 N•m (187 in•lb)
- Temperature Range: -52°C to +177°C
- Cable Impedance: 75 Ohm Triaxial
- Thread Engagement: 21 mm Maximum
Magnetic Field Performance
- 0.5 mm Gap: 0.001 mV/gauss
- 2.5 mm Gap: 0.009 mV/gauss
- 4.6 mm Gap: 0.027 mV/gauss
- Tested up to 300 Gauss
- 60 Hz Magnetic Field Resistance
Temperature Classifications
- T1: -55°C to +232°C
- T2: -55°C to +177°C
- T3: -55°C to +120°C
- T4: -55°C to +80°C
- T5: -55°C to +40°C
Package Contents
- 3300 XL 11mm proximity probe
- ClickLoc connector with protector
- 1.0 meter FluidLoc cable
- Factory documentation
- Approval certificates
Warranty Protection
We provide complete 12-month product coverage. All items are quality tested. Full technical support available.
Global Shipping
Fast delivery via FedEx, UPS, DHL. International shipping available. Order tracking provided.
Installation Notes
Use recommended 21.1 N•m torque. Maximum thread engagement 21 mm. Avoid temperatures below -34°C for seal protection.
Application Uses
Ideal for industrial vibration monitoring. Perfect for metric threaded installations. Suitable for harsh environments.
Frequently Asked Questions
What is the probe thread size?
This probe features M14 x 1.5 metric threading.
What cable length is included?
The probe comes with 1.0 meter FluidLoc cable.
What temperature range can it handle?
Operating range is -52°C to +177°C.
What is the recommended installation torque?
Use 21.1 N•m (187 in•lb) for proper installation.
Does it have agency approvals?
Yes, this model includes multiple agency approvals.
