Schneider Electric Modicon TSX1722028 PLC Module

The Schneider Electric TSX1722028 is a robust PLC module for industrial control systems. This Modicon unit provides reliable digital automation in a standalone configuration. It features ten discrete inputs and ten discrete relay outputs for flexible control. The TSX1722028 operates on standard AC line voltages for easy integration.

Key Technical Specifications

• Manufacturer: Schneider Electric
• Model Number: TSX1722028
• Product Line: Modicon PLC Module
• Module Type: Digital (Discrete) I/O Module
• Input Voltage: 120/240 V AC (Switchable)
• Current Rating: 0.5 AMP @ 120V AC / 0.25 AMP @ 240V AC
• I/O Configuration: 10 Inputs / 10 Outputs
• Output Type: Relay Contacts
• Signal Level for I/O: 24V DC
• Communication Interface: Standalone (No Network Port)
• Mounting Style: Panel Mount
• Module Weight: 1.56 kg / 3.44 lbs

Environmental & Operational Ratings

• Operating Temperature Range: -10°C to +60°C (14°F to 140°F)
• Storage Temperature Range: -40°C to +85°C (Typical for components)
• Operational Humidity: 5% to 95% (Non-Condensing)
• Vibration Resistance: Compliant with industrial standards
• Electrical Isolation: Standard relay isolation between logic and load
• Dielectric Strength: Rated for standard industrial control voltages

Electrical Characteristics & Wiring

• Power Supply: AC Powered directly from line voltage
• Input Type: Digital (Discrete) 24V DC Sinking/Sourcing
• Relay Contact Rating: Typically 2A @ 250V AC resistive
• Response Time: Relay mechanical switching speed (≈10ms)
• Internal Power Consumption: Depends on active relay count
• Wiring Connection: Screw terminal or removable connector type

Installation & Mounting Guide

• Verify your main power is 120V or 240V AC and matches the module setting.
• Mount the module securely on a DIN rail or panel in a vertical position.
• Ensure proper clearance around the module for heat dissipation.
• Connect the AC power leads to the designated L and N terminals.
• Wire your field devices (sensors) to the 10 input terminals as per diagram.
• Connect your output loads (solenoids, lamps) to the 10 relay output terminals.
• Use the correct wire gauge for your load current to prevent overheating.

Packaging & Shipping Details

• Package Includes: 1 x Schneider Electric TSX1722028 PLC Module
• Documentation: May include data sheet or quick start guide
• Shipping Weight: Approximately 2.0 kg (including packaging)
• Shipping Carriers: FedEx, UPS, DHL Express available
• Delivery Timeframe: Varies by location and service selected
• Package Protection: Anti-static and cushioning materials used

Warranty & Support Information

• Warranty Period: 12 months from the date of shipment
• The warranty covers failures due to defects in materials or manufacturing.
• Proper installation within the published specifications is required for coverage.
• Technical support is available to assist with installation and application.

Frequently Asked Questions (FAQ)

• What does "standalone" mean for this PLC module?

It means the TSX1722028 does not have a built-in communication port (like Ethernet or Modbus) to talk to other PLCs or a programming PC. You program it locally, and it runs its logic independently.

• Can I connect 120V AC devices directly to the outputs?

Yes, the relay outputs can switch 120V AC loads directly. The relay contacts separate your control logic (24V DC) from the potentially hazardous line voltage, which is a key safety feature.

• How do I program the TSX1722028?

You will need Schneider Electric's dedicated programming software for the Modicon series (like Unity Pro or earlier PL7) and a compatible programming cable to connect to the module's programming port.

• Is this module suitable for controlling a small machine?

Absolutely. With 10 inputs for sensors/buttons and 10 relay outputs for actuators/indicators, it's perfectly sized for compact machines, conveyor sections, or standalone test stations.

• What happens if the ambient temperature exceeds 60°C?

Sustained operation above the rated temperature can degrade component life and cause unreliable operation. For hot environments, consider additional cooling, derating the loads, or a module with a higher temperature rating.
