330904-00-25-05-02-05 Bently Nevada 3300 NSv Extended Sensor
Manufacturer:
Bently Nevada
Product No.:
330904-00-25-05-02-05
Condition:
In Stock
Product Type:
3300 NSv Extended Sensor
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Pembekal Alat Ganti Automasi Global yang Dipercayai
Kami menawarkan pelbagai alat ganti automasi industri yang tersedia dalam stok. Semua produk datang dengan jaminan 12 bulan dan pemulangan wang dalam 30 hari untuk isu kualiti.
Bently Nevada 3300 NSv Extra Long Armored Probe
Brand new 330904-00-25-05-02-05 armored proximity sensor. Features extra long 250mm case with short cable. Factory fresh in original packaging. This 330904 model reaches deep into machinery for critical measurements.
Model Number Breakdown
- 330904: Armored probe with M8X1 thread
- 00: Zero unthreaded length
- 25: Extra long 250mm case length
- 05: Short 0.5 meter cable length
- 02: Miniature coaxial ClickLoc connector
- 05: Multiple international agency approvals
Complete Technical Specifications
- Brand: Bently Nevada
- Model: 3300 NSv Proximity Probe
- Part Number: 330904-00-25-05-02-05
- Measurement Range: 1.5 mm (60 mils)
- Voltage Output: -1 to -13 Vdc
- Sensitivity: 7.87 V/mm ±20%
- Accuracy: Better than ±0.06 mm
- Frequency Range: 0 to 10 kHz
- Temperature Rating: -52°C to +177°C
- Cable Length: 0.5 meter (20 inches)
- Electrical Resistance: 4.0 ± 0.5 ohms
- Case Material: 304 stainless steel armored
- Probe Tip: Polyphenylene sulfide
- Connector Type: Miniature ClickLoc
- Minimum Target: 13 mm diameter
- Bend Radius: 25.4 mm minimum
- Thread Size: M8x1 standard
- Case Length: 250mm extended reach
- Sealing: Viton O-ring pressure seal
- Weight: Heavy-duty industrial grade
- Installation: Hand tighten only
- Max Torque: 0.56 N•m (5 in•lb)
- Thread Engagement: 12 mm maximum
Installation Instructions
- Set measurement gap at 1.0 mm
- Hand tighten only - no tools needed
- Maximum torque: 0.56 N•m
- Use 13 mm or larger target surface
- Ensure proper thread engagement depth
Expert Technical Questions
- What is the case length? Features extra long 250mm case.
- What cable length is included? Short 0.5 meter cable length.
- What connector type is used? Miniature coaxial ClickLoc connector.
- What approvals does it have? Multiple international agency approvals.
- What is the electrical resistance? Measures 4.0 ± 0.5 ohms.
