70085-1010-002 AI-TEK Speed Sensor - High Output Device
UBEST – Pembekal Alat Ganti Automasi Global yang Dipercayai
Kami menawarkan pelbagai alat ganti automasi industri yang tersedia dalam stok. Semua produk datang dengan jaminan 12 bulan dan pemulangan wang dalam 30 hari untuk isu kualiti.
AI-TEK 70085-1010-002 Speed Sensor - Reliable RPM Detection
Discover the AI-TEK 70085-1010-002 sensor - your trusted solution for accurate speed measurement. This durable sensor delivers consistent performance in tough conditions.
Key Features
- High output voltage - 150V peak-to-peak standard
- Wide temperature range - From -55°C to +107°C
- Robust construction - Built for industrial use
- Easy installation - Standard 5/8-18 thread
- Reliable signals - Clear speed data output
Technical Specifications
- Brand: AI-TEK
- Model Number: 70085-1010-002
- Product Type: Magnetic Speed Sensor
- Standard Voltage: 150V P-P minimum
- Guaranteed Voltage: 12.9V P-P at test point
- DC Resistance: 1500 ohms maximum
- Inductance Value: 360 mH typical
- Output Polarity: Pin B positive
- Thread Size: 5/8-18 UNF
- Thread Length: 1.125 inches
- Sensor Length: 2.25 inches total
- Weight Limit: 5 ounces maximum
- Termination Type: Connector style
- Insulation Resistance: 100MΩ at 500V DC
- Frequency Range: 0-10,000 Hz operational
- Shock Resistance: 100G, 11ms duration
- Vibration Rating: 20G, 20-2000 Hz
Installation Guide
Mount using 5/8-18 thread. Ensure proper gap distance to target. Connect wiring to connector. Check signal output. Secure all connections.
Common Applications
- Engine speed monitoring
- Gearbox RPM measurement
- Motor speed detection
- Conveyor speed control
- Turbocharger monitoring
Shipping Options
We ship worldwide via FedEx, UPS, DHL. Fast processing time. Real-time tracking provided.
Package Includes
- AI-TEK 70085-1010-002 Speed Sensor
- Installation instructions
- Technical data sheet
Warranty Information
12-month product guarantee from delivery date. Quality performance assured.
Professional FAQ
What gap distance should I maintain?
Keep 0.010 to 0.060 inches between sensor tip and gear tooth for optimal signal generation.
Can this sensor work in wet conditions?
Yes, it has sealed construction suitable for environments with moisture and oil exposure.
What connector type does it use?
It features a standard industrial connector compatible with common speed monitoring systems.
How do I verify the sensor is working?
Measure AC voltage output while rotating the target - you should see varying voltage signals.
What target material works best?
Ferrous metals like steel provide the strongest signals, but it works with any magnetic material.
