Siemens 6EP1336-3BA10- High Efficiency Power Supply
UBEST – Pembekal Alat Ganti Automasi Global yang Dipercayai
Kami menawarkan pelbagai alat ganti automasi industri yang tersedia dalam stok. Semua produk datang dengan jaminan 12 bulan dan pemulangan wang dalam 30 hari untuk isu kualiti.
Siemens SITOP PSU8200 480W Power Supply - Premium Industrial Performance
- High-power 24V/20A output for demanding automation systems
- Exceptional 94% efficiency reduces energy costs significantly
- Wide operating temperature from -25°C to +70°C
- Advanced monitoring features with relay contact signaling
Product Overview
The Siemens 6EP1336-3BA10 SITOP PSU8200 delivers premium 480W performance for critical industrial applications. This advanced 6EP1336-3BA10 unit combines high efficiency with robust reliability, making it ideal for demanding automation environments.
Technical Specifications
| Brand: | Siemens |
| Model: | 6EP1336-3BA10 |
| Series: | SITOP PSU8200 |
| Input Voltage: | 120-230V AC / 110-220V DC |
| Output Voltage: | 24V DC |
| Output Current: | 20A continuous |
| Output Power: | 480W typical |
| Efficiency: | 94% |
| Voltage Adjustment: | 24-28V |
| Ripple & Noise: | <100mV |
| Operating Temperature: | -25°C to +70°C |
| Short Circuit Current: | 60A peak |
| Response Time: | 1ms typical |
| Protection Rating: | IP20 |
| Dimensions: | 90 x 125 x 125 mm |
| Weight: | 1.2 kg |
| Mounting: | DIN Rail (35mm) |
Premium Features
- Ultra-high 94% efficiency for energy savings
- Wide temperature range for harsh environments
- Soft start function prevents voltage overshoot
- Dual color LED indicators for status monitoring
- Relay contact output for remote signaling
- Parallel operation supports two units
- Remote ON/OFF control for system integration
- Short circuit protection with auto-recovery
Installation & Setup
Easy DIN rail mounting. Connect using 0.2-4mm² wires. Allow 50mm clearance above and below. Use remote contacts for system control. No derating needed for standard conditions.
Application Areas
- Large PLC control systems
- Industrial robotics
- Process automation
- Machine tool controls
- Factory-wide automation
- High-power sensor networks
Global Certifications
- CE Certified
- UL/CSA Approved
- UKCA Marked
- EAC Compliant
- BIS India Certified
- ABS Marine Approved
- DNV Certified
Package Contents
- SITOP PSU8200 480W Power Supply
- DIN Rail Mounting Clip
- Device Identification Label
- Installation Documentation
- 12-month premium warranty
Shipping Information
Express worldwide shipping via FedEx, UPS, DHL. Orders typically ship within 24 hours.
Frequently Asked Questions
What makes the PSU8200 series different from other SITOP models?
The PSU8200 offers premium features including 94% efficiency, wider temperature range, and advanced monitoring capabilities for critical applications.
Can this power supply operate in cold environments?
Yes, it operates from -25°C and can start up from as low as -40°C, making it suitable for unheated industrial facilities.
How does the efficiency compare to standard power supplies?
At 94% efficiency, it significantly reduces energy costs and heat generation compared to typical 85-90% efficient units.
What is the purpose of the relay contact output?
The relay provides a dry contact signal for remote monitoring systems to indicate when 24V output is within specification.
Can I parallel two units for redundancy?
Yes, two units can be paralleled with appropriate diodes for redundancy or increased power capacity applications.
