140AVO02000 Schneider Analog Output Module

In stock
Manufacturer:
Schneider
Product No.:
140AVO02000
Condition:
In Stock
Product Type:
Analog Output Module
Product Origin:
FR
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Technical Specifications

Attribute Value
Range of Product Modicon Quantum automation platform
Product or Component Type Analogue output module
Analogue Output Number 4
Addressing Requirement 4 output words
Analogue Output Range
  • +/- 10 V >= 1000 Ohm bipolar voltage
  • +/- 5 V >= 500 Ohm bipolar voltage
  • 0...10 V >= 1000 Ohm unipolar voltage
  • 0...5 V >= 500 Ohm unipolar voltage
Analogue Output Resolution 12 bits
Analogue Output Current -10…10 mA
Source Resistance 0.1 Ohm
Maximum Cable Distance Between Devices 1312.3 ft (400 m)
Absolute Accuracy Error +/- 0.15 % of full scale 77.0000000000 °F (25 °C)
Linearity +/- 1 LSB
Accuracy Drift According to Temperature
  • 0.003 % of full scale/°C unipolar
  • 0.004 % of full scale/°C bipolar
  • 0.005 % of full scale/°C maximum unipolar
  • 0.007 % of full scale/°C maximum bipolar
Isolation Between Channels 500 V for 1 minute 47...63 Hz AC
Isolation Between Channels and Bus 780 V for 1 minute AC
Update Time 3 ms
Setting Time 700 µs to +/- 0.1 % of the final value maximum
Bus Current Requirement 700 mA
Maximum Power Dissipation 4.5 W
Associated Fuse Rating 0.063 mA 3 AG fast blow 250 V
Marking CE
Local Signalling
  • For bus communication is present (Active) 1 LED (green)
  • For external fault 1 LED (red)
  • For channel is turned on 4 LEDs (green)
  • For channel fault 4 LEDs (red)
Module Format Standard
Net Weight 0.7 lb (US) (0.3 kg)
Package 1 Height 2.0 in (5.0 cm)
Package 1 Width 6.5 in (16.5 cm)
Package 1 Length 12.4 in (31.5 cm)
