140CPU65160 Schneider Modicon Quantum CPU Module
Manufacturer:
Schneider
Product No.:
140CPU65160
Condition:
In Stock
Product Type:
CPU Module
Product Origin:
France
Weight:
1460g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Overview
Brand: Schneider Modicon
Model: 140CPU65160
Type: Unity Processor
Platform: Modicon Quantum Automation Platform
Key Features
- Clock Frequency: 266 MHz
- Number of Slots: 2, 4, 6, 10, 16
- Number of Racks: 2 local racks
- Web Services: Ethernet router
- Memory: Internal RAM 1024 kB, expandable up to 7168 kB (program) and 8 MB (file storage) with PCMCIA card
- Switch Function: Key switch memory port on/off
Technical Specifications
| Specification | Details |
|---|---|
| Clock Frequency | 266 MHz |
| Number of Distributed I/O Stations | 63 stations (1 rack), 3 Modbus Plus networks |
| Number of Remote I/O Stations | 31 (2 S908 remote I/O racks), 31 (2 Ethernet Quantum remote I/O racks), 16 (2 Ethernet X80 remote I/O racks) |
| Discrete I/O | Unlimited (26 slots max) - local, 31744 inputs/outputs - remote, Unlimited (31 drops of 28 slots max) - Ethernet remote I/O, 8000 inputs/outputs - distributed per network Modbus Plus |
| Analogue I/O | Unlimited (26 slots max) - local, 1984 inputs/outputs - S908 remote I/O, Unlimited (31 drops of 28 slots max) - Ethernet remote I/O, 500 inputs/outputs - distributed per network Modbus Plus |
| Communication Service | Ethernet router |
| Number of Optional Modules | 6 (Ethernet, Modbus, Modbus Plus, Profibus DP, Sy/Max) |
| Maximum Number of Connections | 1 (USB), 2 (AS-Interface) - distributed, 4 (AS-Interface) - remote, 6 (Ethernet TCP/IP) - local, 6 (Modbus Plus) - local, 6 (Profibus DP) - local, 1 (Modbus) - RS232/485 Modbus/ASCII |
| Integrated Connection Type | 1 Modbus Plus, 1 Ethernet TCP/IP, 1 Modbus, 1 USB |
| Execution Time per Instruction | 0.0525-0.075 µs (Boolean), 0.045-0.06 µs (Word), 0.045-0.06 µs (Fixed-point arithmetic), 0.4-0.5 µs (Floating points) |
| Number of Instructions per ms | 15 Kinst/ms (65% Boolean and 35% numerical), 20 Kinst/ms (100% Boolean) |
| System Overhead | 1 ms (master task), 0.2 ms (fast task) |
| Bus Current Requirement | 2760 mA |
Local Signaling
| LED Indicators | Description |
|---|---|
| Green LED | Ethernet activity (COM) |
| Red LED | Ethernet collision |
Electrical Connection
| Connector Type | Description |
|---|---|
| RJ45 | For connecting Ethernet network |
| RJ45 | For connecting Modbus bus |
| SUB-D 9 (Female) | For connecting to the Modbus Plus network |
Environmental Specifications
| Parameter | Value |
|---|---|
| Product Certifications | CE, CSA, GOST, UL, Misc (Marine) |
| Standards | HazLoc |
