140NOC78000 Schneider Modicon Quantum Ethernet DIO Network Module
Manufacturer:
Schneider
Product No.:
140NOC78000
Condition:
In Stock
Product Type:
Ethernet DIO Network Module
Product Origin:
France
Weight:
345g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Product Overview
Brand: Schneider Modicon
Model: 140NOC78000
Type: Ethernet DIO Network Module
Platform: Modicon Quantum Automation Platform
Key Features
- Communication Protocols: Ethernet/IP, Modbus TCP
- Exchange Mode: Full duplex
- Maximum Connections: 128
- Transmission Rate: 10/100 Mbit/s
- Redundancy: Hot standby redundant architecture
- Topology: Redundant ring, daisy chain loop
- Web Server: Embedded
Technical Specifications
| Specification | Details |
|---|---|
| Communication Services | CIP Explicit messaging (client messaging), CIP implicit messaging (I/O communication), FDR server, NTP time synchronization, SNMP agent, embedded 4-port switch, DHCP/BootP server, Quality of Service (QoS), Device Type Manager (DTM) |
| Ethernet Services | Rapid Scanning Tree Protocol (RSTP) |
| Transmission Medium | Twisted pair |
| Port Ethernet | 10BASE-T/100BASE-TX, connector type: RJ45 |
| Supply | Via the power supply of the rack |
| Marking | CE |
| Module Format | Standard |
| Weight | 0.345 kg |
Local Signaling
| LED Indicators | Description |
|---|---|
| Green LED (Active) | Communication on the bus |
| Green LED (Ready) | Configuration status |
| Green/Red LED (Net Status 1) | Device network status |
| Green/Red LED (Net Status 2) | Extended DIO network status |
| Green/Red LED (Mod Status) | Module status |
| Green/Red LED (Net Status) | Network communication status |
Environmental Specifications
| Parameter | Value |
|---|---|
| Standards | CSA C22.2 No 142, EN 55011, EN 61131-2, FM Class 1 Division 2, IEC 61000-4-16, UL 508, EN 61131-1 |
| Certifications | C-Tick, GOST, LR, Hazardous location class 1, division 2, Merchant Navy |
| IP Degree of Protection | IP20 |
| Operating Temperature | 0-60 °C |
| Relative Humidity | 10-95% at 60 °C without condensation |
