1440-SDM02-01RA Standard Dynamic Measurement Module
Manufacturer:
Allen-Bradley
Product No.:
1440-SDM02-01RA
Condition:
In Stock
Product Type:
Standard Dynamic Measurement Module
Product Origin:
USA
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Specification | Details |
|---|---|
| Manufacturer | Allen-Bradley |
| Product No. | 1440-SDM02-01RA |
| Product Type | XM-124 Standard Dynamic Measurement Module |
| Transducer Power |
Constant voltage: 24V DC, -24V DC, 40 mA Constant current (IEPE): 4.5 mA ± 30% / -20% from 24V DC Tachometer: Powered via constant voltage or configured as voltage input |
| Voltage Input Range | -20…0V DC, -10…10V DC, 0…20V DC |
| Input Impedance |
Dynamic Channel Inputs: 100 kΩ Tachometer Input: 120 kΩ |
| Sensitivity | Up to 15% deviation from nominal |
| Tachometer Input Range |
Events per revolution: 1…50,000 RPM range: 1…1,200,000 RPM (0.0167…20,000 Hz) |
| Output Specifications | 4-20 mA with a maximum load of 300 Ω Two isolated outputs |
| Power Supply | 24V DC, 350 mA |
| Power Dissipation | 8.7 W maximum |
