Product Description

The 170180-01-05 Bently Nevada External Transducer I/O Module is a versatile interface module designed to integrate external transducers into Bently Nevada machinery protection and condition monitoring systems. This module allows for the seamless connection of various types of sensors, expanding the monitoring capabilities of the overall system.

Technical Specifications

• Channels: 8 input channels
• Input Signal Types: Eddy current proximity, velocity, acceleration, temperature, and more
• Input Voltage Range: 0 to 24 VDC
• Accuracy: ±0.1% of full scale
• Sampling Rate: Up to 10 kHz per channel
• Power Supply: 24 VDC nominal (18 to 32 VDC range)
• Operating Temperature: -40°C to +70°C
• Relative Humidity: 0 to 95% non-condensing

Physical Specifications

• Dimensions: 228.6 mm x 177.8 mm x 63.5 mm (9 in x 7 in x 2.5 in)
• Weight: 0.27kg
• Mounting: DIN rail or panel mount

Included Components

• 170180-01-05 External Transducer I/O Module
• User manual
• Mounting hardware
