1746-P3 Allen-Bradley Power Supply Module
Manufacturer:
Allen-Bradley
Product No.:
1746-P3
Condition:
In Stock
Product Type:
Power Supply Module
Product Origin:
USA
Weight:
1100g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Category | Specification |
|---|---|
| Manufacturer: | Rockwell Automation |
| Location: | 1746 Chassis, Left Side |
| Input Voltage Range: | 19.2-28.8 VDC |
| Module Type: | Power Supply |
| Series: | SLC 500 |
| Part Number/Catalog No.: | 1746-P3 |
| Brand: | Allen-Bradley |
| Nom Input Voltage: | 24VDC |
| Typical line power requirement: | 90 VA |
| Inrush Current: | 20 A |
| Isolation Voltage: | 600V ac RMS for 1 s (version B or later) |
| Current Capacity: | 3.6 A at 5V dc and 0.87 A at 24V dc |
| Hold Up time: | 5 ms (full load); 1000 ms (no load) |
| Fuse protection: | 1746-F3 or equivalent |
| Temperature, ambient operating: | 0...60 °C (32...140 °F) |
| Current capacity deration: | 5% above 55 °C (131 °F) |
| Input Voltage: | 24 Volts DC |
| Input Power: | 61 Watts |
| Backplane Current (5 Volts): | 3.6 Amps |
| Backplane Current (24 Volts): | 0.87 Amps |
| Frequency: | DC |
| Weight: | 2.5 pounds (1.1 kilograms) |
| Dimensions: | 5.5 x 2.9 x 5.7 inches |
| Operating Temperature: | 0 to 60 degrees Celsius |
