Allen-Bradley 1756-IV32: Ultra-Fast 32-Point ControlLogix Input Module

Critical Performance

• 32-point DC input in single slot
• 2ms ultra-fast response time
• Works with 10-30V DC sensors

Precision Specifications

• Model: Allen-Bradley 1756-IV32
• Input Current: 2mA @10V (min), 3.5mA @30V (max)
• Power Consumption: Only 4.1W max
• Backplane Power: 120mA @5V, 2mA @24V
• Isolation Voltage: 1500V AC (1 minute)
• Weight: 0.55 lbs (0.25 kg)

Industrial Advantages

• 50% more points than standard modules
• Removable terminals (1756-TBCH/TBS6H compatible)
• No external power needed - runs on backplane

Easy Integration

• Plug-and-play with ControlLogix racks
• Works with RSLogix 5000 v8.02+
• LED status indicators per channel

Reliability Features

• Overvoltage protection up to 30V
• ESD shielded design
• Vibration-resistant connectors

Support & Logistics

• 12-month warranty
• Global shipping: FedEx, UPS, DHL
• Next-business-day dispatch

Expert FAQ

• Q: What's the minimum voltage?
  A: Works down to 10V DC
• Q: Can I replace modules without shutdown?
  A: Yes - hot-swappable design
• Q: Are terminal blocks included?
  A: Sold separately (1756-TBCH/TBS6H)
• Q: What's the operating temperature?
  A: 0°C to 60°C (32°F to 140°F)
• Q: How many modules per rack?
  A: Depends on power budget - max 16 modules
