1769-PA4 | Power Supply Module Allen-Bradley
Manufacturer:
Allen-Bradley
Product No.:
1769-PA4
Condition:
In Stock
Product Type:
Power Supply Module
Product Origin:
USA
Weight:
525g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Allen-Bradley 1769-PA4 Technical Specifications
| Parameter | Value |
|---|---|
| Model | 1769-PA4 |
| Part Number/Catalog No. | 1769-PA4 |
| Product Line | CompactLogix |
| Product Type | I/O Power Supply |
| Module Type | AC Power Supply Module |
| Input Power | 120 Volts AC |
| Input Voltage Range | 85…265V AC or 170...265V AC, switch selectable |
| Power Supply Distance Rating | 8; 8 I/O modules can be connected on either side of the power supply for a maximum of 16 modules. |
| Input Frequency Range | 47…63 Hz |
| Shipping Dimensions | 8 x 8 x 5 inches |
| Power Consumption | 200 VA @ 120V AC, 240 VA @ 240V AC |
| Enclosure Type | None (Open Style) |
| Power Dissipation | 8 W @ 60 °C (140 °F) |
| Series | A and B |
| Current Capacity @ 5V DC | 4.0 A |
| Current Capacity @ 24V DC | 2.0 A |
| Wire Type | Copper wire withstanding 90 degrees Celsius |
| Inrush Current, Max | 25 A @ 132V AC |
| Solid Wire Size | 22 to 14 AWG |
| Fuse Type | Littelfuse 02153.15MXP; Wickmann 19195-3.15A |
| Input Frequency | 47 to 63 Hertz |
| Dimensions (HxWxD), Approx. | 118 x 70 x 87 mm (4.65 x 2.76 x 3.43 in.), height including mounting tabs is 138 mm (5.43 in.) |
| Stranded Wire Size | 22 to 16 AWG |
| Weight | 525 g (1.16 lb) |
