ABB 1TGE120010R1000 — Compact MControl Board Module Overview

The ABB 1TGE120010R1000 MControl Board delivers 24VDC power and Modbus TCP/IP connectivity for advanced industrial automation systems. Its fast 45 ms response and 75 ms update interval ensure stable, high-precision control in demanding environments.

Key Features

• Engineered by ABB for reliable performance in distributed industrial control networks.
• Equipped with active cooling to enhance durability under heavy workloads.
• Fully compatible with modern Modbus TCP/IP architectures and automation controllers.
• Compact and modular design simplifies integration into control cabinets.

Technical Specifications

• Brand: ABB
• Model:1TGE120010R1000 (MControl Board Module)
• Input Voltage:24VDC
• Response Time:45 ms
• Update Interval:75 ms
• Mounting Type:DIN Rail
• Network Compatibility:Modbus TCP/IP
• Cooling System:Active Cooling
• Width: 53 mm
• Height: 125 mm
• Depth/Length: 260 mm
• Weight: 0.848 kg
• Country of Origin: USA

Installation Guide

• Mount securely on a standard DIN rail using the integrated snap-latch mechanism.
• Connect 24VDC input to the designated terminals and verify correct polarity before power-up.
• Configure network parameters through Modbus TCP/IP or ABB configuration software.
• Ensure proper ventilation to maintain cooling efficiency and stable operation.

Packaging Contents & Shipping

• 1 × ABB 1TGE120010R1000 MControl Board Module
• 1 × Mounting clip set
• 1 × Terminal label pack
• 1 × Printed user manual
• Ships via Fedex, UPS, or DHL with international tracking and secure packaging.

Warranty & FAQ

• Warranty: 12-month limited warranty from shipment date (terms apply).
• Firmware: ABB provides official firmware updates through authorized support channels.
• Spare Parts: Contact our sales team with model and serial number for replacements.
• Certifications: Available on ABB documentation upon request.
