Bently Nevada 21000-00-00-00-113-00-02 Proximity Probe Housing Assembly

Core Configuration

• Suffix Breakdown: 21000-00-00-00-113-00-02
• 00: Probe not included
• 00: Probe cable not included
• 00: No standoff adapter
• 113: 11.3" (287mm) probe penetration
• 00: Without conduit fittings
• 02: 3/4-14 NPT mounting thread

Technical Specifications

• Material: Aluminum body + 304 stainless steel sleeve
• Weight: 1.1 kg (2.4 lb) without fittings
• Penetration Depth: 11.3" (287 mm)
• Thread Standard: 3/4-14 NPT industrial
• Sealing: Hermetic O-ring seals
• Temp Rating: -50°C to +80°C (T4 certified)

Hazardous Area Certifications

• Class I Div 1/2: Groups C, D
• Class II Div 1/2: Groups E, F, G
• Class III compliant
• CSA Type 4 explosion-proof enclosure
• RoHS 2011/65/EU compliant

Packaging Includes

• Dome cover with threaded ports
• Probe sleeve (287mm length)
• O-ring seals and thread seal
• Mounting hardware kit
• 12-month warranty card

Shipping Information

New original unit. Ships worldwide via FedEx, UPS, or DHL within 24hrs.

FAQ

Q: Does this include proximity probes?
A: No. Suffix 00 = probe/cable not included.

Q: Certified for North American refineries?
A: Yes. CSA-certified for Class I Div 1/2 Groups C&D (oil/gas).

Q: Minimum installation clearance?
A: Requires 11.3" axial space plus wrench clearance.
