Overview:

The Bently Nevada 21000-16-10-00-077-03-02 Proximity Probe Housing Assemblies are specifically engineered for use in hazardous environments. These assemblies feature explosion-proof designs, CSA approvals, and are fully compliant with API 670 standards for externally mounted proximity probe housings. The product is ideal for intrinsically safe applications, offering a reliable and durable solution for various industrial sectors.

Technical Specifications:

• Model: 21000 - Proximity Probe Housing Assemblies.

• Manufacturer: Bently Nevada.

• Condition: New, original in factory packaging.

• Warranty: 12-month factory warranty.

• Material: Aluminum body with 304 stainless steel sleeve.

• Weight: 1.1 kg (2.4 lb), typical without fittings.

21000-16-10-00-077-03-02 Suffix Code Breakdown:

• -16: 3300 XL 8 mm probe.

• -10: 1.0 m (39 in) probe cable length.

• -00: No standoff adapter (standard option).

• -077: Probe penetration of 7.7 in.

• -03: Fitting option includes:

• 1/8 to 3/16 inches.

• 1/4 to 5/16 inches.

• 5/16 to 3/8 inches.

• One 3/4-14 NPT plug.

• One 3/4-14 to 1/2-14 NPT reducer.

• One cable seal grip with grommets for various cable sizes:

• -02: Mounting thread option – 3/4-14 NPT (must be ordered if no standoff adapter is selected).

Dimensions and Cable Lengths:

• Maximum Probe Visibility Dimension (C + D):

• 0.5 m cable: 13.5 in (34.3 cm) maximum visibility dimension.

• Probe is not visible with 1.0 m cable length.

Included Components:

• Dome cover that screws into the housing.

• Threaded ports for conduit connections.

• Optional probe sleeve length.

• 0-rings, reverse mount proximity probe, and thread seal.

• Optional conduit fittings and standoff adapter.
