Overview:

The Bently Nevada 21000-16-10-00-256-03-02 Proximity Probe Housing Assembly is designed for use with 3300 XL 8mm probes. It provides a reliable solution for industrial applications requiring precise proximity measurement, particularly in hazardous environments. This product is CSA-approved, explosion-proof, and compliant with API 670 standards, making it suitable for hazardous area installations.

Technical Specifications:

• Model: 21000 Proximity Probe Housing Assembly

• Manufacturer: Bently Nevada

• Material: Aluminum body with 304 stainless steel sleeve

• Dimensions:

• Maximum probe cable length: 1.0 m (39 in)

• Maximum dimension (C) + (D): 13.5 in (34.3 cm)

• Weight: 1.1 kg (2.4 lb) without fittings

• Approval: CSA Type 4 enclosure; explosion-proof

• Mounting Thread: 3/4-14 NPT

• Suffix Codes:

• -16: 3300 XL 8mm probe option

• -10: 1.0 m cable length

• -256: 25.6 in probe penetration

• -03: Includes 3/4-14 NPT plug, reducer, and cable seal grip for various cable sizes

• -02: 3/4-14 NPT thread (if no standoff adapter is used)
