Bently Nevada 21000-16-10-15-098-03-02: Long-Reach Explosion-Proof Housing

Deep Penetration Monitoring Solution

Industrial probe housing with 9.8" penetration depth for hard-to-reach measurements. CSA Type 4 explosion-proof certified for hazardous areas. Aluminum body with stainless steel sleeve construction. Factory new with 12-month warranty.

Technical Specifications

• Part Number: 21000-16-10-15-098-03-02
• Probe: 3300 XL 8mm with connector
• Cable: 1.0m (39") length
• Penetration: 9.8" (248mm)
• Material: Aluminum body + 304SS sleeve
• Max Visible Probe: 17.0" (43.18cm)
• Total Length: 32.9" (83.5cm)
• Weight: 2.4lb (1.1kg)

Configuration Details

• 21000 - Base housing assembly
• 16 - 3300 XL 8mm probe
• 10 - 1.0m cable length
• 15 - 1.5" standoff adapter
• 098 - 9.8" probe penetration
• 03 - Conduit fitting kit
• 02 - 3/4-14 NPT mount

Unique Performance Features

• Hazardous Certification: Class I Div 1 & 2 Groups C/D
• Temperature Rating: T4 @ -50°C to +80°C
• Sealing System: Triple O-ring protection
• Cable Grip: Accommodates 1/8" to 3/8" cables
• Conduit Compatibility: 1/2" to 3/4" NPT fittings

Compare Similar Models

• 21000-28-05-00-057-04-02
  • Shorter 5.7" penetration
  • Different probe type (28)
  • 0.5m cable length
  • Alternative fitting kit (04)
• 21000-16-10-15-070-03-02
  • 7.0" penetration depth
  • Same standoff adapter
  • Identical cable length
  • Different fitting configuration
• 21000-28-10-20-039-04-02
  • 3.9" penetration only
  • 2.0" standoff adapter
  • Alternative probe type (28)
  • Different fitting kit (04)

Installation Guide

1. Apply thread sealant to NPT connections
2. Select correct grommet for cable size
3. Ensure O-rings are properly seated
4. Verify 17" minimum clearance for probe

Package Contents

• 21000 housing assembly
• 3/4-14 NPT fittings kit
• Cable seal grip with grommets

• Installation manual

Warranty & Shipping

• 12-month manufacturer warranty
• Global delivery: FedEx, UPS, DHL
• Hazardous materials packaging

Expert Support

1. Q: Minimum clearance required?
   A: 32.9" total length space needed
2. Q: Compatible with other probes?
   A: Designed for 3300 XL 8mm probes
3. Q: Suitable for outdoor use?
   A: Yes, Type 4 enclosure rating
4. Q: Maximum cable diameter?
   A: Accommodates up to 3/8" cables
5. Q: Pressure rating for seals?
   A: Certified for explosive atmospheres
