Overview

The 21000-28-05-00-065-00-02 Proximity Probe Housing Assembly by Bently Nevada is designed for use in hazardous area environments, offering rugged protection and reliable performance. This assembly includes a variety of options for probe, cable length, standoff adapter, and mounting thread, making it versatile for different industrial applications. The unit is CSA certified and explosion-proof, ensuring safety in demanding environments. The assembly features a durable aluminum housing with a 304 stainless steel sleeve, offering both protection and ease of installation.

Technical Specifications

• Brand: Bently Nevada

• Model: 21000

• Material: Aluminum body with 304 stainless steel sleeve

• Weight: 1.1 kg (2.4 lb) typical, without fittings

21000-28-05-00-065-00-02 Suffix Codes Meaning:

• -28: 3300 XL 8 mm probe, selectable with hazardous area approvals

• -05: 0.5 m (20 in) probe cable length

• -00: No standoff adapter

• -065-: 6.5 in probe penetration

• -00: Without fittings

• -02: 3/4-14 NPT mounting thread (must be ordered if Standoff Adapter Length Option is -00)

Key Components:

• Dome cover screws into the housing body

• Threaded ports for conduit connections

• Optional probe sleeve length

• Reverse mount proximity probe

• Thread seal and optional conduit fittings

• Optional standoff adapter

Approvals:

• CSA Certified

• Explosion-Proof for Hazardous Areas

• API 670 Standard Compliance
