Overview:

The Bently Nevada 21000-28-05-15-050-03-02 Proximity Probe Housing Assemblies offer superior performance in hazardous environments. These assemblies are ideal for monitoring machinery vibration and ensuring precise measurement in industrial applications. Designed to meet CSA standards, the housings are explosion-proof and available with optional conduit fittings and standoff adapters. Additionally, the aluminum body and stainless steel sleeve ensure durability and resistance in harsh conditions.

Technical Specifications:

• Brand: Bently Nevada

• Model: 21000

• Material: Aluminum body with 304 stainless steel sleeve

• Dimensions: 13.5 in (34.3 cm) max length with probe

• Weight: 1.1 kg (2.4 lb) typical without fittings

• Approval: CSA certified for hazardous areas, explosion-proof

• Housing: Type 4 enclosure per API 670 standards

• Warranty: 12 months factory warranty

• Part Contents:

• Dome cover, O-rings, thread seal, optional standoff adapter, and conduit fittings

• Fittings Included:

• One 3/4-14 NPT plug

• 3/4-14 to 1/2-14 NPT reducer

• Cable seal grips for multiple cable sizes

Suffix Codes and Options:

• Probe Option:

• -28: 3300 XL 8 mm probe, hazardous area approvals

• Probe Cable Length:

• -05: 0.5 m (20 in)

• Standoff Adapter:

• -15: Minimum length 1.5 in (38 mm)

• Probe Penetration:

• -050: 5 in

• Fitting Option:

• -03: Includes one plug, reducer, and cable seal grips for various cable sizes

• Mounting Thread Option:

• -02: 3/4-14 NPT (required if Standoff Adapter Length Option is not -00)
