Overview

The Bently Nevada 21000-28-10-00-217-04-02 Proximity Probe Housing Assembly is engineered to offer optimal performance in hazardous environments. It features a robust aluminum body with a 304 stainless steel sleeve, ensuring both durability and resistance to corrosion. This assembly is CSA certified and explosion-proof, making it ideal for safety-critical industrial applications. The housing assembly includes flexible options such as probe length and standoff adapter to cater to various installation needs.

Technical Specifications

• Brand: Bently Nevada

• Model: 21000

• Material: Aluminum body with 304 stainless steel sleeve

• Weight: 1.1 kg (2.4 lb) typical, without fittings

21000-28-10-00-217-04-02 Suffix Codes Explanation:

• -28: 3300 XL 8 mm probe, selectable with hazardous area approvals

• -10: 1.0 m (39 in) probe cable length

• -00: No standoff adapter

• -217-: 21.7 in probe penetration

• -04: One 3/4-14 NPT plug only

• -02: 3/4-14 NPT mounting thread (required if Standoff Adapter Length is not -00)

Key Components:

• Dome cover screws into the housing body

• Threaded ports for conduit connections

• Optional probe sleeve length

• Reverse mount proximity probe

• Thread seal and optional conduit fittings

• Optional standoff adapter

Approvals:

• CSA Certified

• Explosion-Proof for Hazardous Areas

• API 670 Standard Compliance

• Type 4 Enclosure Certification
