Allen-Bradley 2198-D032-ERS3 | Kinetix 5700 Dual-Axis Servo Drive

The 2198-D032-ERS3 is a high-performance dual-axis servo drive. It delivers precise motion control for industrial applications. This drive offers excellent power density and reliability. It integrates seamlessly with Ethernet/IP networks.

Technical Specifications

• Brand: Allen-Bradley
• Model: 2198-D032-ERS3
• Series: Kinetix 5700
• Type: Dual-axis Servo Drive
• Continuous Current: 13A RMS
• Peak Current: 18.3A RMS
• Input Voltage: 380-480V AC
• Power Output: 8.9kW @ 480V
• DC Bus Current: 13.7A
• PWM Frequency: 4kHz
• Torque Rating: 0.5-0.6 N·m
• Communication: EtherNet/IP
• Protection Rating: IP20
• Operating Temperature: 0°C to 60°C
• Storage Temperature: -40°C to 85°C
• Humidity: 5-95% non-condensing
• Vibration Resistance: 2G
• Shock Resistance: 15G
• Altitude Rating: 3000 meters
• Dimensions: 358 x 55 x 250 mm
• Weight: 4.16 kg

Easy Installation & Setup

Install the 2198-D032-ERS3 quickly in your control panel. Connect to EtherNet/IP for fast commissioning. The compact design saves valuable space. It meets strict industrial environmental standards.

Warranty & Shipping

We provide a 12-month warranty on the 2198-D032-ERS3. We ship worldwide via FedEx, UPS, and DHL. Your order will be processed quickly and shipped securely.

Expert FAQs

What communication protocol does this drive use?

It uses EtherNet/IP for seamless integration with Allen-Bradley systems.

How many axes does this drive control?

The 2198-D032-ERS3 controls two independent servo axes.

What input voltage does it require?

It operates on 380-480V AC mains power.

What is the peak current capability?

It delivers 18.3A RMS peak current for high-demand applications.

Is this drive suitable for harsh environments?

Yes, it withstands 2G vibration and 15G shock in industrial settings.
