23733-03 Bently Nevada Accelerometer Interface Module
Manufacturer:
Bently Nevada
Product No.:
23733-03
Condition:
In Stock
Product Type:
Accelerometer Interface Module
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Specification | Details |
|---|---|
| Part Number | 23733-03 |
| Manufacturer | Bently Nevada |
| Series | 3300 |
| Supply Voltage | -23 Vdc to -26 Vdc |
| Current Draw | 22 mA maximum |
| Operating Temperature | +32° F to +158° F (0° C to 70° C) |
| Charge to Voltage Conversion | Converts the charge input from the accelerometer into a low impedance voltage signal, scaled to 10 mV/g peak (1.02 mV/m/s² peak). |
| Filtering | Applies a 12th-order bandpass filter |
| Velocity Conversion | 100 mV/in/s peak (3.94 mV/mm/s peak) sensitivity. |
| Accelerometer Compatibility | Supports accelerometers with sensitivities of 50 pC/g or 100 pC/g |
| Bias Voltage | The nominal bias for both +VELOCITY and +ACCEL outputs is -10 Vdc. |
