24765-03-01 Case Expansion Transducer Assembly
Manufacturer:
Bently Nevada
Product No.:
24765-03-01
Condition:
In Stock
Product Type:
Case Expansion Transducer Assembly
Product Origin:
USA
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🛠 Technical Specifications
Model Information
| Parameter | Specification |
|---|---|
| 🏢 Brand | Bently Nevada |
| 🔢 Model | 24765-03-01 |
| ⚙️ Series | Case Expansion Transducer |
Measurement & Performance
| Parameter | Specification |
|---|---|
| 📏 Linear Range | 101.6 mm (4.00 in) |
| 🔧 Spring Return Option | Yes (Spring return included) |
| 🔋 Operating Voltage | DC power supply (12V-24V typical) |
| 📐 Accuracy | ±0.01 mm (±0.0004 in) |
| 📏 Resolution | 0.001 mm (0.00004 in) |
Dimensions & Mounting
| Parameter | Specification |
|---|---|
| 📏 Length | 150 mm (5.91 in) |
| 📐 Width | 60 mm (2.36 in) |
| 📏 Height | 45 mm (1.77 in) |
| 🔩 Mounting Type | Flanged mounting |
Electrical & Environmental Performance
| Parameter | Specification |
|---|---|
| 🔋 Operating Voltage | DC power supply (12V-24V typical) |
| 🌡️ Operating Temperature Range | -40°C to 85°C (-40°F to 185°F) |
| 🌐 Environmental Protection | IP65 rated for dust and water resistance |
| 🔌 Output Signal | 0-10V DC proportional to displacement |
Certifications & Compliance
| Parameter | Specification |
|---|---|
| 🛡️ Certifications | CE marked, UL listed |
| ♻️ Compliance | RoHS compliant |
