Triconex 2770H | HART Interface Module

The Triconex 2770H enables advanced HART communication for process control systems. This interface module connects with 3700A and 3721 compatible modules. It provides reliable data acquisition for industrial automation applications.

Key Features & Benefits

• 32 input channels for high-density signal processing
• HART protocol support revisions 5.0 through 7.0
• Dual signal compatibility with 4-20mA and 0-5VDC inputs
• Low power consumption under 5 Watts operation
• Visual status indicators for quick diagnostics

Technical Specifications

• Brand: Triconex
• Model:2770H
• Input Channels: 32 signals
• 极
• Input Types: 4-20 mA, 0-5 VDC
• HART Protocol: Revision 5.0-7.0
• Power Consumption: < 5 Watts
• Compatible Modules: 3700A, 3721
• HART MUX Module: 2071H (includes 4850 Multiplexer)
• Operating Temperature: -40°C to 70°C
• Storage Temperature: -40°C to 85°C
• Humidity Range: 5% to 95% non-condensing
• Isolation Voltage: 1500V AC channel-to-channel
• Update Rate: 4 updates per second per channel

Installation & Setup

• Mounting: Standard DIN rail or panel mount
• Wiring: Use shielded twisted pair cables
• Configuration: Triconex programming software required
• Indicator Lights: PWR, FAULT, HOST, HART status
• Calibration: Field adjustable zero and span

Package Contents

• One Triconex 2770H interface module
• Installation documentation
• Mounting hardware kit
• Connection terminal blocks

Shipping & Delivery

• Carrier Options: FedEx, UPS, DHL Express
• Processing Time: 1-2 business days
• International Shipping: Available globally
• Tracking Information: Provided for all orders
• <极
• Customs Documentation: Complete paperwork included

Warranty & Support

• Warranty Coverage: 12 months warranty

Technical Assistance: Factory support availableReturn Policy: 30-day satisfaction guarantee

Frequently Asked Questions

• What modules work with the 2770H?
  It connects with Triconex 3700A and 3721 compatible modules.
• How many input signals can it handle?
  The module supports up to 32 input channels.
• What HART protocol versions does it support?
  It works with HART protocol revisions 5.0 through 7.0.
• What input signal types are accepted?
  It accepts both 4-20mA current and 0-5VDC voltage signals.
• What is the power consumption?
  The module uses less than 5 Watts during operation.
