Triconex 3101 Main Processor Module

The Triconex 3101 main processor module delivers high-performance control for critical safety systems. This robust processor features dual 32-bit architecture for reliable operation in demanding industrial environments.

Technical Specifications

• Model Number: 3101
• Processors: Dual Motorola MPC860 32-bit
• Clock Speed: 50MHz
• DRAM: 16MB (SX) + 16MB (IOX)
• Flash PROM: 6MB CRC-protected
• NVRAM: 8KB for retentive variables
• Operating Voltage: 24VDC (-15%/+20%)
• Power Consumption: 8W maximum
• Communication: 2Mbps HDLC diagnostic bus
• Weight: 1.5kg (3kg shipping)
• Temperature Range: -40°C to +70°C

Package Contents

• One (1) Triconex 3101 Main Processor Module
• Installation documentation
• Mounting hardware

Shipping & Warranty

• Includes 12-month warranty
• Worldwide shipping via FedEx, UPS, and DHL
• Orders processed within 1-2 business days

Frequently Asked Questions

• Q: What processors does the 3101 module use?
  A: It features dual Motorola MPC860 32-bit processors running at 50MHz.
• Q: How much memory does this module have?
  A: It includes 16MB DRAM, 6MB Flash PROM, and 8KB NVRAM.
• Q: What is the operating voltage range?
  A: It operates from 19.2VDC to 30VDC with 5% AC ripple tolerance.
• Q: Does this module support redundant operation?
  A: Yes, it features triple modular redundant architecture for safety systems.
• Q: What communication protocols are supported?
  A: It includes a 2Mbps HDLC diagnostic bus for module communication.
