Overview

The Bently Nevada 3330106-05-30-05-12-CN is a high-performance Reverse Mount Probe designed for reliable measurements in challenging conditions. Engineered in the U.S.A, this model ensures precise monitoring through its robust construction and advanced materials.

Technical Specifications

• Brand: Bently Nevada
• Model Number: 3330106-05-30-05-12-CN
  • 3330106-05-30: Indicates M10 x 1 threads
  • -05: Specifies total Length 05 0.5 meter (1.6 feet)
  • -12: Indicates the FluidLoc cable option.
  • -CN: Represents country-specific approvals.
• Product Type: Reverse Mount Probes
• Total Length Option:
  • Length: 0.5 meters (1.6 feet).
• Connector Option:
  • Type: Miniature ClickLoc coaxial connector, FluidLoc cable (considered optional).
• Agency Approval Option: Country Specific (CN).
• Dimensions: 20.4 cm x 22.2 cm x 3.7 cm.
• Weight: 0.323 kg.

Electrical Specifications

• Nominal Probe DC Resistance (RPROBE):
  • For a length of 0.5 meters: 7.45 ± 0.50 Ohms.

Mechanical Specifications

• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 303 or 304 stainless steel (SST).
• Maximum Probe Case Torque:
  • Maximum Rated Torque: 22.6 N•m (200 in•lbf).
  • Recommended Torque: 7.5 N•m (66 in•lbf).
• Probe Case Thread: M10x1 with a maximum length of 15 mm for thread engagement.
